1. working flowchart and support machine of the BBQ wood sawdust charcoal briquettes making machine
1. Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass material without any additive
5. Carbonized the briquette stick
The other charcoal/ coal sawdust briquette making machine display
Specifications of the wood sawdust briquettes manufacturing machines
There are two types machine
(1)Single machine
If the capacity you need is 120-450kg/h, you can choose one single machine, about the single machine, we have six types.
|
Model
|
Capacity kg/h
|
Power kw
|
Material temperature
|
Weight kg
|
Packing dimension mm
|
|
ZBJ50-9
|
120-220
|
11-15
|
8-12% |
550
|
2200×600×1300
|
|
ZBJ50-C
|
350-420
|
22
|
8-12% |
750
|
2700×700×1550
|
|
ZBJ60-9
|
220-250
|
15-18.5
|
8-12%
|
650
|
2400×700×1350
|
| ZBJ70-9 | 280-340 | 18.5-22 | 8-12% | 780 | 2400×700×1400 |
| ZBJ80-9 | 320-360 | 22 | 8-12% | 850 | 2400×750×1400 |
| ZBJ90-9 | 380-450 | 30 | 8-12% | 980 | 2600×800×1500 |
(2)Automatic Production line
If you need large capacity, one single machine can not meet your need, you can choose several sets of single machine, or use the automatic production line, the automatic production line have a large capacity ( from 800kg-2500kg/h),and it will save many workers and cost.
Our automatic line include the main machines and auxiliary Machinery .the main machine (several sets of single briquette machine) Auxiliary machine (material distributor, screw conveyor, belt conveyor, smoke disposal system, cool conveyor.
|
Model
|
Capacity
|
Power (kw)
|
Dimensions, m
|
Bar Diameter, mm
|
Weight, MT
|
|
ZBJ9-4-1
|
900-1100kg/h
|
11*5+3+3+ 0.22
|
6.5*2.35*3.1
|
50,60,70
|
3.2
|
|
ZBJ9-4-2
|
1250-1500kg/h
|
15*5+3+3+0.22
|
6.5*2.35*3.1
|
50,60,70,80
|
3.8
|
|
ZBJ9-5-1
|
1800-2200kg/h
|
11*10+3*2+3+0.22*2
|
6.5*3.35*3.15
|
50,60,70
|
6.4
|
|
ZBJ9-5-2
|
2200-2500kg/h
|
15*10+3
|
6.5*3.35*3.15
|
50,60,70,80
|
7.5
|
(1)Pre-sales service
a. Sales team will suggest suitable project.
b. Technical team analyse and design special molds for you.
c. Pick you up at airport, arrange hotel-booking.
d. Other travel arrangements.
(2)After-sales service
a. Assist you build up factory and production li ne.
b. Install and maintain machines.
c. Training your workers to achieve skillful operation.
d. Offer technical support through telephone or online videos at any time.
Our shipping terms
We can accept EXW FOB and CIF terms. Also our freight forwarding has high effieiency and quick shipping speed.If stock machine,we can send out your products within 5 days.If you need special molds or customized producion line, the delivery time according to you machine quantity, but we will send out as soon as possible.
As a professional manufacturer in exporting charcoal/biomass briquette plants for agro-forestry wastes, we are leading a team working to exploit full set of various manufacturing and exporting briquetting equipments, including charcoal/biomass briquette machine, straw fuel briquette press, pellet mill, conveyor and grass chipper
