Professional Stainless Automatic RO Water Purifier System

Specifications

RO water purifier system
1.Various capacities available
2.CE, ISO9001
3.Easy operation & maintenance
4.Stable operation

RO water purifier system

1. Applications of RO water purifier system

        RO water purifier system is widely used in industries such as medical, pharmaceutical, electronic, electrical, chemical, food and beverage, textile printing and dyeing, general houses and community drinking water supply etc.



2. Working principle of RO water purifier system

        RO water purifier sytem is a kind of pressure driven by a semipermeable membrane, the selection of interception function, the solution of the solute and solvent separation separation method. They are widely used in various liquid separation and concentration. Water treatment process, water, inorganic ion, bacteria, virus, organic matter and colloid and other impurities are removed, to obtain a high quality water.



3. Working Process of RO water purifier system

      1.) Raw water pump -- provide the pressure to quartz sand filter/active carbon filter.

      2.) Multi-medium filter -- get rid of turbidity, suspended matter, organic matter, colloid, ect.

      3.) Active Carbon filter -- Remove the color, free chloride, organic matter, harmful matter, ect.

      4.) Softener-- exchange "ions" of calcium and magnesium with the most common and easiest method.

      5.) Micron filter -- prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.

      6.) High pressure pump -- Provide the high pressure to RO membrane.

      7.) RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.

      8.) Water tank.



4. Paranmeter of RO water purifier system

NO. Name Model Material 1 multi-media filter diameter:300mm FRP 2 silica sand   lily white 3 Pre processing pipeline   PVC 4 Precision filter 5core20inch Stainless steel 5 Precision filter 5μm PPm 6 High pressure pump CDL8-180 Stainless steel 8 RO embrance 4040   9 Flowmeter 1-6ton Oranic glass 10 Solenoid valve 40,50 Brass 11 Pressure regulating valve 50 Brass 12 Pressure gauge 10,30kg Quake proof 13 Conductivity meter CM—230 PE 14 Low voltage switch 220V PE 15 AB switch 220V PE 16 power distribution     17 The host pipe   PVC 18 rack   Stainless steel 19 pure water tank 4T Stainless steel

5. Features of RO water purifier system

      1.) All products adopt all-around computer aided design (CAD) .All auxiliary parts adopt international and domestic famous brand products.

      2.) Original water pump,mechanical filter,activated carbon filter,ultrafilter high pressure pump, RO systems ,cleaning system, high and low pressure protection system ,automatic liquid level control system ,automatic alarm system ,automatically stop when the water tank is full, automatically run when the is empty.

      3.) The system owns low energy consumption and saves energy effectively. Running state and parameter online real-time display.

      4.) The system used the current domestic advanced technology, trying to reduce the engineering investment, shorten the construction period, reduce the operation cost.

      5.) We have a strong research and development team and perfect after-sale service system.



6. How to get your suitable machine?

      • Find our products through Gongyi Hengxin in .

      • Enquiry: Contact us by Email, Skype, Fax, Tel, Trademanager and let us know your enquiry.

      • Discussion: Specify the items you desire, confirm specification.

      • Quotation: Prices offered and accepted.

      • Place order as per contract or discussion.

      • Order completed under our arrangement.

      • Goods shipped as per contracted term.

      • Goods arrive at local port or warehouse, depending on contracted term.



Any question about this machine,contact with us please ,sincere service for you ,and welcome to Gongyi Hengxin.



7. Guarantee And After-sale Service

      • One year guarantee for whole machine and forever technical support.

      • We will send some spare parts freely for to change it.

      • 24 hours technical support by E-mail.

      • Calling or door-to-door service.

      • Use-friendly English software,user manual.

      • We can send our engineer to your factory for installation and train your staff,but you should pay the round air tickets and arrange the hotel accommodation and the means for our engineer.
