Centrifugal Type Automatic Dephosphorization Edible Oil Filter

Name: Centrifugal Type Automatic Dephosphorization Edible Oil Filter
Brand: hengxin
SKU: 141416398
Availability: InStock

US$ 1,000 - 1,500 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Suction Filter

Structure:

Vacuum

Gongyi Hengxin Material Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao china

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Suction Filter

Structure Vacuum

Place of Origin Henan, China

Brand Name hengxin

Model Number YXLJ-425

Power(W) 3KW,380v,50HZ

Weight 150KGS

Dimension(L*W*H) 550*550*900MM

Certification CE,ISO,SGS

Warranty 2 years

After-sales Service Provided Engineers available to service machinery overseas

Features edible oil filter

high filtration speed,filter 10-15kgs oil for 425 Model in 2-4 minutes (25-35kgs oil for 500 model in same time ),just you need to clean the residue when the oil handling volume reached to 500kgs
no consumption of spare parts , no need washing the filter cloth
electricity saving,stop the power once barrate rotating speed goes into regular ,then use the centrifugal force to separate

Caution of edible oil filter :

Do not start the machine without closing the caps and fixing the anchor bolt .
The permissible oil residue percentage is 1-1.5%,and the ratio of salt and water should be near 1:10 , for example ,if you wanna to filter 100kgs oil ,probably 1.2-1.5kgs water is needed to pour in when the oil temperature reached to 60-70 degree, then stir two minutes
There are oil hole on the sidewall of oil feed hopper ,pls keep refill the edible oil 3 times in one day to prevent conflict bearings happened.
Refasten the bolt which located on the filter bottom after periods to prevent oil leak .

Specifications for all Models edible oil filter

Problems and Solutions of edible oil filter

Business Card

Details Photos of edible oil filter

painting surface

chroming surface
