Home > Industrial Equipment & Components > Filtration Equipment & Parts > Oil Filter > Purify Cooking Oil / Centrifugal Force Dephosphorization Edible Oil Refiner
Purify Cooking Oil / Centrifugal Force Dephosphorization Edible Oil Refiner
US$ 1,000 - 1,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Suction Filter
Structure:
Vacuum
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Reliable China Chromed Centrifugal Type Cooking Oil Filter SupplierUS$ 1,000 - 1,500MOQ: 1 Set -
Best Selling Centrifugal Crude Cooking Oil Filter PlantUS$ 1,000 - 1,500MOQ: 1 Set
-
Widely Used Screw Vegetable Oil Processing MachineUS$ 3,200 - 3,500MOQ: 1 Set
-
High Output Rate Automatic Screw Type Cooking Oil MakerUS$ 3,200 - 3,500MOQ: 1 Set
-
Screw Automatic Oil Mill for Mustard SeedUS$ 3,200 - 3,500MOQ: 1 Set
Condition
New
Type
Suction Filter
Structure
Vacuum
Place of Origin
Henan, China
Brand Name
hengxin
Model Number
YXLJ-425
Power(W)
3KW,380v,50HZ
Weight
150KGS
Dimension(L*W*H)
550*550*900MM
Certification
CE,ISO,SGS
Warranty
2 years
After-sales Service Provided
Engineers available to service machinery overseas
Working Principle of Edible Oil Refiner
Use the centrifugal force by rotating the barrate in a high speed to separate the suspending impurity and oil ,and when barrate stop rotating the clean oil flows and goes into the storage tank ,as testing this oil can be edible ,no froth ,no overflow.
Features of Edible Oil Refiner
- high filtration speed,filter 10-15kgs oil for 425 Model in 2-4 minutes (25-35kgs oil for 500 model in same time ),just you need to clean the residue when the oil handling volume reached to 500kgs
- no consumption of spare parts , no need washing the filter cloth
- electricity saving,stop the power once barrate rotating speed goes into regular ,then use the centrifugal force to separate
Caution of edible oil refiner :
- Do not start the machine without closing the caps and fixing the anchor bolt .
- The permissible oil residue percentage is 1-1.5%,and the ratio of salt and water should be near 1:10 , for example ,if you wanna to filter 100kgs oil ,probably 1.2-1.5kgs water is needed to pour in when the oil temperature reached to 60-70 degree, then stir two minutes
- There are oil hole on the sidewall of oil feed hopper ,pls keep refill the edible oil 3 times in one day to prevent conflict bearings happened.
- Refasten the bolt which located on the filter bottom after periods to prevent oil leak .
Specifications for all Models edible oil refiner
Problems and Solutions edible oil refiner
Business Card
Details Photos of edible oil refiner
painting surface
chroming surface
