16kw Reefer Underslung genset for Chile
This generator is mounted under the trucks, and supplys the electric power to refrigerated containers. It's powered by Laidong / Yanmar brand diesel engines and coupled with Marathonalternators. The control system can offer the automatic protection with LCD display. We have 100L fuel tank and socket as option. The pictuers in attachment for your reference.
Tech specification
Genset Model |
PFY16XL-M |
PF16GFXL-M |
||
GENSET |
Rated power(Kw/kva) |
16/20 |
16/20 |
|
Frequency(Hz) |
60 |
60 |
||
Phase |
3 |
3 |
||
Voltage(V) |
460 or 440 |
460 or 440 |
||
Fuel capacity(L) |
200 |
200 |
||
Fuel consumption(L/Hour) |
4.8 |
5.8 |
||
Dimension (mm) |
L |
1435 |
1520 |
|
W |
1160 |
1200 |
||
H |
820 |
960 |
||
Weight(kg) |
570 |
590 |
||
Noise level for silent type (Db/7m) |
70 |
70 |
||
ENGINE |
Model |
4TNV88-GGE YANMAR BRAND |
4L22BD-4 LAIDONG BRAND |
|
Cylinders |
4 |
4 |
||
Type |
Vertical, 4-cycle water-cooled diesel engine |
Vertical,4-cycle water-cooled diesel engine |
||
Starting method |
Starting motor 12V,1.4kw |
Starting motor 12V,1.4kw |
||
ALTERNATOR |
Model |
GM-16-4 |
GM-16-4 |
|
Manufacturer |
Marathon |
Marathon |
||
Insulation class |
H |
H |
||
Excitation method |
Brushless self-excitation |
Brushless self-excitation |
||
Package: plywood case or plastic wrapping
Warranty:
We provide guarantee for 500 running hours or 6 months for range from the min to 50kW (including 50kW) genset; 1000 running hours or 12 months for range from 50kW to the max genset (whichever comes first). Warranty doesn’t' cover spares such as filters, V-belt, etc. Malfunctions caused by misoperation and careless maintenance will not be considered by us.
