Specifications
Dual Fuel Turbine Generator1.Cummins Engine
2.Containerized Genset
3.ISO/CE Guaranteed
4.Global Warranty
China Manufacturer 1MW Diesel/Gasoline Dual Fuel Turbine Generator
Advantages of choosing Dual Fuel Turbine Generator
1. Engine which includes wet type cylinder, direct injection combustion chamber, exhaust turbocharger, water cooling, electronic governor, etc.
2. Air intake and exhaust system, which includes air filter, exhaust silencer, bellow, all intake and exhaust piping, cablings, instruments, valves and settings, etc.
3. Cooling system, which includes radiator with water level alarm and indicator, thermostatic switch, thermostatic heater, engine shaft mounted fan, all interconnecting piping, cablings, instruments, valves and settings, etc.
4. Lubricating system includes pumps, oil sumps, oil strainers and filters, all interconnecting piping, instruments, valves and settings, etc.
5. Starting system, which includes 2 sets of batteries, a set of AC charger, and interconnecting piping, cablings, instrument, valves and settings, etc.
Parameters of Dual Fuel Turbine Generator | |
| Genset | PFC1250 |
| Diesel Engine | KTA50-G3 |
| Alternator | Leroy Somer |
| Control Panel | Deep Sea |
| Prime Power | 1250kVA/1000kW |
| Standby Power | 1375kVA/1100kW |
| Diesel Consumptiom | 254L/h |
| Cylinder Number | 16 |
| Bore*Stroke | 159*159 |
| Displacement | 50.3L |
| Dimension(mm) | 4980*2040*2410 |
| Weight(kg) | 8550 |
| Connceting Type | 3 Phase 4 Wires |
| Rated Voltage | 230/400V adjustable |
| Frequency | 50Hz |
| Rotating Speed | 1500rpm |
| Excitation Type | Brushless Self-excitation |
| Voltage Regulation(steady state) | ≤ ±1% |
| Voltage Regulation(transient state) | ≤ +20% -15% |
| Frequency Regulation (steady state) | ≤ ±1% |
| Frequency Regulation (transient state) | ≤ +10% -7% |
| Sudden Voltage Warp | ≤ 1% |
| Frequency Waving | ≤ 1% |
| Voltage Stable Time(sudden) | ≤ 1s |
| Frequency Recovery Time(sudden) | ≤ 3s |
| Wave Warp | ≤ 5% |
Certificate:ISO,CE,GOST Approved
Package:plastic wrapping or plywood case
Delivery time: 20~30 working days
Payment: By telegraphic transfer: 30% deposit on signing of sales contract; and balance 70% before dispatch
Guarantee for one year or 1000 hours whichever reach first from ex-factory date.
Warranty:We provide guarantee for 500 running hours or 6 months for range from the min to 50kW (including 50kW) genset; 1000 running hours or 12 months for range from 50kW to the max genset (whichever comes first). Warranty doesn' t cover spares such as filters, V-belt, etc. Malfunctions caused by misoperation and careless maintenance will not be considered by us.
Dalian Puyang Generating Set Co.,Ltd. has become the leading generating set manufacture in Northen China.We have the largest scale of production and full product specifications and models.We also have the only one full-funtion testing center in northern China.
Rightnow, we are doing well in over twenty provinces, cities and regions in China, our diesel genetators are serving in most fields such as : voyage, railway, mines, oil fields, transportation, hospital war industries, aerial defense, seaports, telecommunication, energy sources, shopping centers, food and drinks service, construction, etc. We also provide the comprehensive and high quality service for our customers including: factory design, installation direction, free testing, free training, periodical return vidsiting, quality tracking, etc.
''Let the light and power eternal'' is all the clients' wish, it's also our tenet of service.We are sure to win everybody's support and trust through our best qulity of products and service.
