Help CenterAdvanced Design and High Quality Integrated Oil Extractor
Related Products
-
Automatic Multifunctional Combined Oil PressUS$ 100 - 9,999MOQ: 1 Set -
Advanced Convenient Quality Moringa Oil PressUS$ 100 - 9,999MOQ: 1 Set
-
Coco Flesh Oil Press MachineUS$ 100 - 9,999MOQ: 1 Set
-
Advanced Sunflower Automatic Screw Oil PressUS$ 100 - 9,999MOQ: 1 Set
-
Combine Oil PressUS$ 100 - 9,999MOQ: 1 Set
Specifications
1.High oil output rate2.Press many oil seeds
3.High equipment quality
4.ISO9001:2008&CE
5.Long durablity
Introduction:
The screw oil press is the introduction of technologies and South Korea and China Cereals, Oils & Food Research Institute of Agricultural Mechanization Research Institute developed a new generation of energy-efficient oil extraction equipment, in line with the Ministry of Agriculture Agricultural screw press technical conditions and standards requirements, its processing oil production of genuine, pure fidelity, is to create a "modern oil mill," the best choice.
Features for screw oil press:
Energy Conservation ---- An equal decrease in the production of electric power 40%, saving an average of 6 kilowatt-hour basis, daily production could be 30 Yuan to save electricity.
Save Labor---- 1~2 operators , Save labor about 60%
Wide usage---- multi-purpose machine,used in peanut,sesame,soy,grease,benne etc. 3 squeeze, a squeeze in net
Pure oily ---- Vacuum filtration residue to protect the purity of the oil quality in line with health and quarantine standards.
Technical parameters
|
model Technical parameter |
6YZ-80(1685) |
6YZ-100(1688) |
6YZ-150(D1698) |
|
|
Diameter of worm section |
80mm |
100mm |
150mm |
|
Rotary speed of worm section |
50-60rounds/min |
40rounds/min |
45 rounds/min |
|
Diameter of inscribed circle of press boring |
82mm |
102mm |
152mm |
|
|
Equipped force |
Main frame |
Y132-6-5.5KW |
Y132M6-7.5KW |
Y160L-4 15KW |
Vacuum pump |
Y80-4-0.55KW |
Y801-4-1.1KW |
Y905-4 1.1KW |
|
heater |
3KW |
3.5KW |
6KW |
|
Capacity |
80-150kg/h |
150-250kg/h |
230-500kg/h |
|
Weight |
780kg |
1100kg |
1800kg |
|
|
Overall dimension (L*W*H) |
1800*1300*1750 |
1980*1450*1800 |
2300*1700*1800 |
|
Performance of oil expression
Oil material |
Oil press rate (%) |
Thickness of the material slag |
Residual oil ratio (%) |
sesame |
42-55 |
1.0-1.5 |
≤7 |
peanut |
40-50 |
0.8-2 |
≤8 |
rapeseed |
28-43 |
1.0-1.5 |
≤8 |
Sunflower seeds |
30-40 |
1.2-1.5 |
≤8 |
Soy bean |
10-16 |
0.8-1.5 |
≤7 |
