Description of JS Concrete Mixer
JS Concrete Mixer developed by our company is widely used by our global users. This machine can be used as a separated mixing machine or used as the supporting machine of the ready mix concrete plant. When matched with batching plant, they can form a simple mixing plant.
Features of JS Concrete Mixer
1.As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.
Application of JS Concrete Mixer
This concrete mixer can be used to mix stiff-consistency concrete, semi-stiff-consistency concrete, lightweight aggregate concrete and so on.
Technical Specification of JS Concrete Mixer
COMMODITY NAME | Forced concrete mixer | |
MODEL | JS500 | |
SPECIFICATION | 1.discharging height :1.5m(2.7m/3.8m) 2.discharging form: manual operation/ air operated | |
BRAND NAME | Tiema | |
PLACE OF ORIGIN | China | |
MOTOR POWER | 0.75KW | |
MIXING POWER | 18.5KW | |
LIFTING MOTER | 5.5KW | |
CHARGING CAPACITY | 800L | |
DISCHARGING CAPACITY | 560L | |
MAX.PRODUCTIVITY | 25M3/H | |
SPEED OF MIXING DRUM | 35r/min | |
NUMBER OF BLADES | 2*7 | |
MAX. AGGREGATE SIZE
| scree
| 80mm |
aggregate | 60mm | |
OUTLINE DIMENSION (mm)
| Transport dimensions
| 3030*2300*2680 |
Working dimensions | 4486*3030*5280 | |
WEIGHT | 4000KG | |
Note: The above technical parameters are just for your reference.
