US$ 40 - 1,000 MOQ: 100 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JH
Model Number:
JH-MB
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name JH
Model Number JH-MB
After-sales Service Provided No overseas service provided
Application

Suction Guide is mounted directly on a centrifugal
pump and eliminates a number of fittings like


  • long radius bend


  • conventional strainer


  • straight pipe at pump suction


  • flanges, nuts, bolts, gaskets

Principle of operation

The water flow is passed through an in-built
strainer to remove suspended solids and then guided to the pump suction through
flow straighteners. Fine mesh filter provided helps to prevent seal failure and
instrumentation damage during commissioning.

 Benefits



-Provides optimum flow
conditions at the pump inlet
-

Reduction in pipework and
number of pipe fittings, reducing system pressure drop

-

Minimises space
requirement

-

Lower initial
cost

-

Improves pump
efficiency

-

Overall reduction in
installation and operating costs
