Help CenterHigh Performance Butterfly Valve
US$ 200 - 500
MOQ: 150 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Universal Flange Wafer Butterfly ValveUS$ 40 - 1,000MOQ: 150 Pieces -
Europe Type Butterfly ValveUS$ 40 - 1,000MOQ: 150 Pieces
-
Industrial U.S.A Butterfly ValveUS$ 40 - 1,000MOQ: 150 Pieces
-
Full PTFE Coated Butterfly Valve-Cast Iron BodyUS$ 40 - 1,000MOQ: 150 Pieces
-
Full PTFE Coated Butterfly Valve-Stainless Steel BodyUS$ 70 - 2,000MOQ: 150 Pieces
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Low Pressure
Power
Manual
Material
Casting
Temperature of Media
Low Temperature
Media
Water
Port Size
4
Place of Origin
Shandong, China
Model Number
Wafer_ BV
Brand Name
Jiahe
Specifications
High performance Butterfly ValveHigh performance Butterfly Valve
Features:
- Size: 2" to 36" wafer type, lug type
- Designs: ANSI 609; ISO 5752
- Materials: Body: Carbon steel; CF8 and CF8M Disc:SS304 and SS316 Shaft:SS416 and SS316;17-4pH. Seat: RPTFE; SS304 Bushing: Bronze and Glass backed PTFE
- Working Pressure: 2" to 6" 40 bar, 8" to 36" 25bar
Specification:
- The double offset design of the double eccentric butterfly valve assures reduced seat wear and bidirectional seal, zero leakage. When open the valve, the disc does not contact the seat, so the seat life is extended and operating torques are reduced, then it is more easier for user's operating.
- General: Standard valves tested to MSS SP-61. API 598 testing available on request.For 2" through 36" sizes: Face-to-face dimensions meet, within specified tolerance, MSS SP-68 and API 609 requirements
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer, Trading Company
Year Established
2008
Factory Size
5,000-10,000 square meters
Total Employees
51 - 100 People
