Home > Industrial Equipment & Components > Valve > Ball Valve > Universal Flange Wafer Butterfly Valve

Universal Flange Wafer Butterfly Valve

Name: Universal Flange Wafer Butterfly Valve
Brand: Jiahe
SKU: 141412048
Availability: InStock

Universal Flange Wafer Butterfly Valve thumbnail-1

Universal Flange Wafer Butterfly Valve photo-1

US$ 40 - 1,000 MOQ: 150 Pieces

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Butterfly

Pressure:

Low Pressure

Contact Supplier Request Quote Chat Now

Shandong Jiahe Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Butterfly

Pressure Low Pressure

Power Manual

Material Casting

Temperature of Media Low Temperature

Media Water

Port Size 4

Place of Origin Shandong, China

Model Number Wafer_ BV

Brand Name Jiahe

Specifications

Europe type Butterfly valve

Wafer Butterfly Valve

·Valve Standard:Comply with EN593/BS5155/MSS SP-67.

·Working Pressure and Temperature

Size 50 to 600,working pressure PN 16/Class 125.

Size 50 to 300,working pressure PN 20/Class 150.

Size 50 to 300,working pressure PN 25/Class 250.

Temperature from -10°C to 120°C for EPDM liner.

Temperature from -10°C to 82°C for NBR liner.

Temperature from -10°C to 150°C for Viton liner.

·Top Flange standard: Comply with ISO5211/1.

·Flange Type:EN1092-2 PN10/PN16/PN25,ANSI B16.1 Class125, ANSI B16.2 Class250,BS10 Table D/E,JIS 10K/16K.

·Operator:Handle or gear operator.

·Materials Specification

Part Name	Material	EN Spec.	ASTM Spec.
Body	Cast Iron	EN-JL1040	A126 Class B
Shaft	Stainless Steel	BS970 420S37	AISI 420
Disc	Stainless Steel	BS970 304S15	A351 CF8
	Bronze	EN1982 CC491K	B62 C83600
	DI Nichel Plated or FBE Coated	EN-JS1050	A536 65-45-12
Bushing	PTFE	Commercial	Commercial
Liner	EPDM/NBR/VITON	Commercial	Commercial
O-Ring	EPDM/NBR/VITON	Commercial	Commercial
