Low Consumption 30TPD Corn Milling Machine for Corn Grits and Flour

30TPD corn milling machine for corn grits and flour

Brief introduction of 30TPD corn milling machine:

This production line is employed for the hulling, gritting and milling of corn. After the hulling treatment of the product, the net kernels were sent to the gritting and milling chamber. Then through the process of crushing and grinding, high quality grits and flour were produced.

Main machine of 30TPD corn milling machine

Buckwheat elevator, high efficient vibrating sifter, gravity destoner, manetic selector, corn hulling machine, corn polishing machine, fine corn grits machine, milling machine, square plantisifter, low and high pressure fan....

Characteristics of 30TPD corn milling machine

1. Simple structure and low investment, different configuration according requirements

2. Our advanced enginner has 17 years working experience

3.The core machines are developed by ourself, have a patent

4. well reserved after service.

Parameters of output

Products:             corn grits,flour,huskers;

Yields:                 grade corn grits 42%-50%;

                              corn flour 25%-30% ;

                              huskers 20%-25%,

                total output of corn grits and flour 75%-80%

Corn flour finess: 40-120 mesh (adjustable).

Technical Parameters of 30TPD corn milling machine

Capacity: 30t/d

Totaled power:  81.4 kw

Machines totaled weight: About 27t

Installation steel structure dimensions:  12*5*7m

Installation structure:

The line has simple structure, high adjustability for the field area and the workshop, no special requirements. Effectively cut down the fixed investment; Simple installation, fast construct progress, short construction period, allow our clients to meet the benefits in the shortest possible time.

The process of maize flour grits and flour milling

1.Grain storage ( silos, or warehouse)

2.Cleaning part ( sifter, destoner, separator, magnet, scourer, etc)

to clean out the middle and small impurity from corn. e.g., dust, stone, magnetic material,

corn was bitten by insect and so on.Includes beating, screening, destoner, magnetic separator

and dampening.this section is make the wheat/corn to prepare for millling part and to protect

the machinery as well.

vibrating screen                                       destone machine

3.Milling part  (roller mill, plan sifter, purifier, impact detacher, etc.)

Include different number of mill and sifter to mill the corn and separate the flour and bran

(1) Mill: mill the wheat/corn to break the integrity by the roller moving

(2) Sifter: to separate the flour and bran, also separate large size and small size to enssure

flour quality..

   polishing machine                                 electric/pneutic mill

4.Automatic packing part

The packing part can be manual one also can be auto one, this can be designed according to

requirement and machine capacity.

5.Precast pipe, network

Used in grain processing plants and for air conveying and dedusting in feed plants

6.Final Products

 7. Packing and shiping

We also offer the follwing production line

20t/d-2000t/d series of  corn product line (flour)

series of multi corn product line (grits, flour, germ)

series of dual corn product line (germ, flour)

Corn gluten meal production line

Wheat flour milling production line

Whole wheat flour milling production line

Buckwheat processing line

....

Our Service

We provide precise design proposal. Including detailed quotation List, CAD flow chat,technological index, installation diagram,and provide installed production line video and photos for customers reference.

We provide standard shipping wooden package, full set of equipments photos before and after packing goods.also, full set of shipping documets sent by post. Engineers is available to install machine oversea.

Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes,man-made problems, etc will be responsible for clients-self.

If you need more technical information and exactly price, please contact with us freely.Our professional technique team will give you the best service.
