200tpd maize milling plant for maize grits, flour
Specification
* easy operation and daily manitenance
* 1 set MOQ
* 30days delivery after recieve payment
* long lifetime with imported spare parts form Sweden, USA&Japan
Chuanyue Machinery Co.,Ltd is a professional manufacturer of all types of flour milling machine for wheat/maize/corn and rice, integrating development and production together.
Our products are exported to Belgium, Egypt, Algeria, Zambia, Kenya, Ethiopia, Uganda, Tanzania, Vietnam, and other countries.
Technical parameter of the maize milling plant
| Model | Power (kw) | Capacity (t/d) | Dimensions L*W*H(m) |
| 6FYDT-30 | 81.4 | 30 | 10*5*8 |
| 6FYDT-50 | 179.6 | 50 | 18*5*8 |
| 6FYDT-100 | 312.6 | 100 | 24*7*9 |
| 6FYDT-150 | 478.34 | 150 | 34*7*9 |
| 6FYDT-200 | 768.14 | 200 | 38*7*10 |
Yields: grade maize grits, grade maize flour & huskers
The output ratio can be adjusted according clients' requirements.
Introduction of the maize corn milling plant?
Function of the maize milling plant, maize milling plant line
1. Maize milling machine, maize mill machine, maize flour mill machine, maize flour milling machines, maize milling plant, maize milling plant line
2. Cleaning, peeling, crushing, polishing and sieve classifying into flour, grits as per customer's different requirements.
Main features of the maize milling plant, maize milling plant line
1. Unrivaled peeling efficiency removing corn skin, corn germ, root and black hilum, final output is in consistent color without any black dot. And the corn grits comes from the hard or horny endosperm, corn flour comes from the soft or floury endosperm.
2. You can adjust the fineness wheel on the right of the machine to get more than 20 sizes of corn grits from half corn seeds to corn flour.
3.Resonable designation and easy operation and daily maintenance.
4. Long lifetime due to imported spare parts from Sweden, USA & Japan.
5. One year quality guarantee and free spare supply fpr one year
Maize milling plant line
Main Machines
Cleaning system: | Beat: to remove dust, sand small seed, bacterial count and insect seed.
|
Screening: to remove large and small impurities in the maize seed.
| |
Destoner: to remove stone in the maize.
| |
Magnetic separator: remove metal material in the maize
| |
Dampening: ensure the bran’s integrity during the milling process
| |
Peeling and germ system: | Peeling crusher: to make the maize to small size.
|
Germ separator: to separate the germ from these maize materials.
| |
Flour milling system: | Mill: to break the integrity by the roller moving |
Sifter: to separate the flour and bran also separate large size and small size to ensure flour quality.
| |
Packing system: |
Packed from 1kg -50kg per bag |
Output: grade maize grits, maize flour
We provide comprehensive sales service, including pre-sales service, on-sales service and after-sales service as below chart.
If you need more technical information and exactly price, please contact with us freely.
Our professional technique team will give you the best service.
