Specifications
XPS Foam Board Extruder1.Good quality
2.Material can be recycle
3.High efficiency
4.Reasonable price
XPS Foam Board Extrusion Line
Products: Foam insulation board
Material: PS
Blowing agent: Freon, F12/F22
Thickness: 20 - 100mm
Width range: 600, 900, 1200mm
Density: 30 - 35 kg/M3
Edge profile: Ship lap, Tongue and Groove
Surface profile: RC grooving; Overlapping and SS flush joint
Type: Tandem
Screw Diameter: 120/150 mm, 135/150mm
Screw L/D: 34: 1 and 32: 1
Throughput: 220-350 Kg/h.
Cooling: by water
Total power: 310KW
Dimension: 40X8.2X5.5 m (L.W.H)
Weight: 20 MT
Delivery time: 75days
Product Description: XPS foamed board, also named as polystyrene extrusion plastic board (XPS for short) has a perfect closed-cell structure. Its density, water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower than those of other heat insulation materials and they are characterized by strong intensity, light material, airtight, anticorrosion, aging resistance, low cost. It has been widely used for heat preservation, and insulation in the construction industry, frost resistance of the highway, railway, airport, square and household fitment. It is the generally acknowledged as the best heat preservation material at present.
THE MAIN TECHNICAL SPECIFICATIONS:
EXTRUSION SYSTEM |
|
ONE |
TWO |
SCREW DIA |
mm |
135 |
150 |
L/D RATIO |
|
32 |
34 |
HEATING ZONE |
|
9 |
12 |
HEATING POWER |
KW |
42 |
63 |
DRIVING MOTOR POWER |
KW |
75 |
90 |
|
OTHER | |||
THICKNESS OF BOARD |
mm |
202530405060100 |
|
WIDTH OF BOARD |
mm |
6009001200 |
|
LENGTH OF BOARD |
mm |
1200125024502500 |
|
EDGE OF BOARD |
|
SS Flat |
|
OUTPUT |
Kg/h |
280 |
|
DIMENSION(L*W*H) |
mm |
40000*8200*5500 |
|
TOTAL WEIGHT (APPR.) |
T |
20 |
|
Note: The above-mentioned data is only for your reference and we keep the rights for modification of the component and machinery structure. The relevant contents involved in equipment purchase should be subject to the contract.
