Specifications
FRP products applicationstructural FRP products are used everywhere
Product features
·corrosion resistant
·Slip resistant-special anti skid surface or the natural concave top
·Light weight-Density 4 times less than steel & 1 times less than that of aluminum
·Low maintenance(no rusting, no painting)
·Non-conductive-does not carry electric current
·Radio Frequencies(FR) and Electromagnetic transparency
·Aesthetic appealing-improve plant look with attractive colors
·Impact resistant
·Easy to cut and fabricated-hand cutting tools required only
·Lowest in life cycle cost
Products available
·Color
Standard colors: Green, Yellow, Gray, Orange
Custom colors: any color to match your needs
·Surface
A concave
B smooth
C post grit
D embedded grit
E covered with smooth surface
F covered with patten
G covered with grit
Standard resin systems Available
Resin code | description | Resign base | Corrosion resistance | Flame spread rating | Max. temp |
Type GP | Architectural or applications with moderate corrosion | orthophthalic | good | ASTM E-84,class 1,25 or less | 150°F |
Type I | Industrial application | isopthalic | Very good | ASTM E-84,class 1,25 or less | 150°F |
Type V | High chemical resistance | Vinyl ester | excellent | ASTM E-84,class 1,25 or less | 200°F |
Type XVE | Premium grade with extra fire resistance | Vinyl ester | excellent | ASTM E-84,class 1,10 or less | 200°F |
Type F | Meet US FDA food industry standard | ISO | good | ASTM E-84,class 1,30 or less | 150°F |
Type P | Low smoke and superior fire resistance | phenolic | excellent | ASTM E-84,class 1,0 | 300°F |
Products specification
thickness | mesh | Load bar | Panel size | Weight(kg/sqm) | Open area |
Square mesh | |||||
13 | 50X50 | 7/5 | 1220X3660 | 5.80 | 78% |
25 | 38X38 | 7/5 | 1525X3960 | 12.49 | 69% |
30 | 38X38 | 7/5 | 1525X3960 | 14.89 | 68% |
38 | 38X38 | 7/5 | 1525X3960 | 19.40 | 68% |
50 | 50X50 | 7/5 | 1525X3960 | 23.52 | 71% |
40 | 40X40 | 7/5 | 1527X4047 | 19.34 | 67% |
rectangular | |||||
25 | 25X100 | 9.8/5 | 1220X3660 | 13.52 | 68% |
38(treads) | 38X152 | 7/5 | 572X3660 | 17.50 | 77% |
Mini mesh | |||||
22 | 40X40 (20X20) | 7/5 | 1527X4047 | 16.30 | 42% |
30 | 40X40 (20X20) | 7/5 | 1527X4047 | 18.56 | 42% |
38 | 40X40 (20X20) | 7/5 | 1527X4047 | 23.78 | 42% |
38 | 38X38 (19X19) | 7/5 | 1220X3660 | 23.65 | 41% |
Micro mesh | |||||
22 | 40X40 (8X8) | 7/5 | 1527X4047 | 16.78 | 34% |
30 | 40X40 (8X8) | 7/5 | 1527X4047 | 19.73 | 34% |
