We supply FRP products contains molded grating, pultruded grating, pultrusion, handrail, ladder and safety cage.
PULTRUDED GRATING
Product process
In this method, continuous fibreglass rovings and mats are pulled through a liquid resign bath, shaped through a series of forming guides, and then drawn through a heated steel die that takes the shape of the resulting part.
Upon existing the die, the part is 90% to 95% cured.
Product features
·Maximum Strength
·Unidirectional
·Light weight
·Low maintenance
Products available
·Color
Standard colors: yellow, gray
Custom colors: any color to match your needs
·Surface
Grit top
Grating with cover(grit,pattern,smooth)
Products specification
In metric
Grating type |
height |
width |
Open area |
Bearing bar space |
#bearing bar/ft |
Bearing bar center |
Weight(kg/sqm) |
I series | |||||||
I-6010 |
25mm |
15mm |
60% |
22.5mm |
8 |
38mm |
11.22 |
I-5010 |
25mm |
15mm |
50% |
15mm |
10 |
30mm |
14.63 |
I-4010 |
25mm |
15mm |
40% |
10mm |
12 |
25mm |
17.56 |
I-6015 |
38mm |
15mm |
60% |
22.5mm |
8 |
38mm |
16.10 |
I-5015 |
38mm |
15mm |
50% |
15mm |
10 |
30mm |
19.02 |
I-4015 |
38mm |
15mm |
40% |
10mm |
12 |
25mm |
21.95 |
T series | |||||||
T-1810 |
25mm |
38mm |
18% |
7.5mm |
8 |
45mm |
14.14 |
T-3310 |
25mm |
38mm |
33% |
12.5mm |
5 |
50mm |
12.19 |
T-3320 |
50mm |
25mm |
33% |
12.5mm |
8 |
38mm |
19.51 |
T-5020 |
50mm |
25mm |
50% |
25mm |
6 |
50mm |
15.12 |
In inch
Grating type |
height |
width |
Open area |
Bearing bar space |
#bearing bar/ft |
Bearing bar center |
Weight(lb/sqft) |
I series | |||||||
I-6010 |
1" |
0.6" |
60% |
0.9" |
8 |
1.5" |
2.3 |
I-5010 |
1" |
0.6" |
50% |
0.6" |
10 |
1.2" |
3.0 |
I-4010 |
1" |
0.6" |
40% |
0.4" |
12 |
1" |
3.6 |
I-6015 |
1.5" |
0.6" |
60% |
0.9" |
8 |
1.5" |
3.3 |
I-5015 |
1.5" |
0.6" |
50% |
0.6" |
10 |
1.2" |
3.9 |
I-4015 |
1.5" |
0.6" |
40% |
0.4" |
12 |
1" |
4.5 |
T series | |||||||
T-1810 |
1" |
1.5" |
18% |
0.3" |
8 |
1.8" |
2.9 |
T-3310 |
1" |
1.5" |
33% |
0.5" |
5 |
2" |
2.5 |
T-3320 |
2" |
1" |
33% |
0.5" |
8 |
1.5" |
4.0 |
T-5020 |
2" |
1" |
50% |
1" |
6 |
2" |
3.1 |
