Help CenterLight Green Frp Pultruded Grating
Related Products
Specifications
Product featuresMaximum Strength
Unidirectional
Light weight
Low maintenance
PULTRUDED GRATING
Product process
In this method, continuous fibreglass rovings and mats are pulled through a liquid resign bath, shaped through a series of forming guides, and then drawn through a heated steel die that takes the shape of the resulting part.
Upon existing the die, the part is 90% to 95% cured.
Product features
·Maximum Strength
·Unidirectional
·Light weight
·Low maintenance
Products available
·Color
Standard colors: yellow, gray
Custom colors: any color to match your needs
·Surface
Grit top
Grating with cover(grit,pattern,smooth)
Products specification
In metric
Grating type |
height |
width |
Open area |
Bearing bar space |
#bearing bar/ft |
Bearing bar center |
Weight(kg/sqm) |
I series | |||||||
I-6010 |
25mm |
15mm |
60% |
22.5mm |
8 |
38mm |
11.22 |
I-5010 |
25mm |
15mm |
50% |
15mm |
10 |
30mm |
14.63 |
I-4010 |
25mm |
15mm |
40% |
10mm |
12 |
25mm |
17.56 |
I-6015 |
38mm |
15mm |
60% |
22.5mm |
8 |
38mm |
16.10 |
I-5015 |
38mm |
15mm |
50% |
15mm |
10 |
30mm |
19.02 |
I-4015 |
38mm |
15mm |
40% |
10mm |
12 |
25mm |
21.95 |
T series | |||||||
T-1810 |
25mm |
38mm |
18% |
7.5mm |
8 |
45mm |
14.14 |
T-3310 |
25mm |
38mm |
33% |
12.5mm |
5 |
50mm |
12.19 |
T-3320 |
50mm |
25mm |
33% |
12.5mm |
8 |
38mm |
19.51 |
T-5020 |
50mm |
25mm |
50% |
25mm |
6 |
50mm |
15.12 |
In inch
Grating type |
height |
width |
Open area |
Bearing bar space |
#bearing bar/ft |
Bearing bar center |
Weight(lb/sqft) |
I series | |||||||
I-6010 |
1" |
0.6" |
60% |
0.9" |
8 |
1.5" |
2.3 |
I-5010 |
1" |
0.6" |
50% |
0.6" |
10 |
1.2" |
3.0 |
I-4010 |
1" |
0.6" |
40% |
0.4" |
12 |
1" |
3.6 |
I-6015 |
1.5" |
0.6" |
60% |
0.9" |
8 |
1.5" |
3.3 |
I-5015 |
1.5" |
0.6" |
50% |
0.6" |
10 |
1.2" |
3.9 |
I-4015 |
1.5" |
0.6" |
40% |
0.4" |
12 |
1" |
4.5 |
T series | |||||||
T-1810 |
1" |
1.5" |
18% |
0.3" |
8 |
1.8" |
2.9 |
T-3310 |
1" |
1.5" |
33% |
0.5" |
5 |
2" |
2.5 |
T-3320 |
2" |
1" |
33% |
0.5" |
8 |
1.5" |
4.0 |
T-5020 |
2" |
1" |
50% |
1" |
6 |
2" |
3.1 |
