Description
The series of double shaft shredder adopts PLC automatic control with the functions of starting ,stopping,reversion and overload automatic reversion.It is low speed,high torque and low noise.The shaft block adopts split type that will be easy to change,remove and install the blades.Application:various containers,plastic barrel,waste packaged plastic,packing case,plastic tray,TV,laundry machine,refrigerator shell,tyre,various waste metal(Cu,Te,Al) sheet.Food waste,living waste and medical waste.
Applications
To process plastic material: thick wall diameter plastic pipes, plastic film, waste injection products,
plastic bottles, bags, and so on.
strong crushing shredders
contrarotation with the structure of close-lined rotary knives in double direction.
Features
A. This machine is widely used for shredding big material such as tires, wood, big roll film and similar items that can not be crushed by single shaft shredder;
B. Precisely processed combined frame made of extra-thick plates; Lange-angle, hexagon prism of power slewing axis; Big hopper with big caliber for feeding big material;
C. PLC control system with positive and negative auto running and auto stopping function to protect the machine when the material feed exceeds;
D. Low running speed with low noise and little dusty;
E. Equipped with main electrical apparatus of famous brand such as Schneider and etc.;
F. Customization is available.
Technical parameter
| Model | LD1200 | LD1500 | LD1800 | LD2000 |
| Size of inlet(mm) | 1500*2000 | 1800*2000 | 2000*2300 | 2600*2300 |
| Cutter diameter(mm) | 400 | 530 | 530 | 650 |
| Thickness of blade(mm) | 40 | 50 | 50 | 75 |
| Spindle speed(r/min) | 6-15 | 6-15 | 6-15 | 6-15 |
| Motor power(kw) | 45*2 | 55*2 | 75*2 | 90*2 |
| Dimension | 4200*1700*2600 | 6100*2500*3100 | 7000*2600*3200 | 7300*2800*3200 |
FAQ
We will give you factory price with full specification, so pls leave us an inquiry to know more details about price,packaging shipping and discount.
Now,please click the following contact to send us email for best offer and more details!
↓↓↓
Web:
Henan Hongke Heavy Machinery Co.,ltd
Tel Fax:86-371-68617124
Phone:86-15236618748
