Specifications
Rotary Drier1. High level automatic running
2. Nice performance
3. Reliable working conditions
4. With ISO certificate
Rotary Drier
Brief Introduction of Rotary Drier: |
1. The Rotary Drier is depending on the practice in sand and stone production, absorbing the leading technology home and abroad, and is widely used in sand making industry.
2. The Rotary Drier is of high efficiency and has the features of reasonable structure, high capacity and low consumption.
3. The Rotary Drier can make final products free from dirt and impurities and reduce the high quality sand loss.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Application of Rotary Drier: |
The Rotary Drier is mainly used in building material, metallurgy, chemical industry, cement plant for drying of limestone slag, coal powder, slag, and clay stone. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure of Rotary Drier: |
The Rotary Drier consists of the cylinder, before and after the roller circle, a large gear, gear roll, drag roller, a small gear, a feeding device, lifting plate, reducer, motor, feeding device and other components. Furnace can be designed according to user needs, the combustion chamber, bucket elevator, belt conveyor, feeder, dust and other system equipments.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Principle of Rotary Drier: |
Materials are sent to hopper of rotary drier by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Technical Parameter of Rotary Drier: |
|
