Energy Saving Rotary Dryer For Coal Powder
- any main port in China
- T/T
You May Like
Product Details
| Condition | New | Type | Rotary Drying Equipment | |
| Place of Origin | Henan, China | Brand Name | HK | |
| Model Number | multi-model for rotary dryer for coal powder | Voltage | 380V/50HZ | |
| Power(W) | 4KW | Dimension(L*W*H) | 0.6*8m | |
| Weight | 5.1t | Certification | ISO9001 | |
| Warranty | 3-5 years | After-sales Service Provided | Engineers available to service machinery overseas |
standard export packing or nude packing for rotary dryer for coal powder
Product Description
Specifications
rotary dryer for coal powder1. High durability
2. Large throughput
3. Stable working conditions
4. ISO, CE, BV certificate
Energy Saving Rotary Dryer For Coal Powder
Rotary Dryer For Coal Powder Introduction
Rotary Dryer For Coal Powder is widely used for drying materials in the industries of cemet, mine, contruction, chemical, food, compoud fertilizer, etc. Feeding and discharging unit is installed with thermocouple to control drier temperature. The temperature change of drier's feeding end can be indicated by the thermometer to control the inner drier temperature ( generally 250-350°C).
First is Three-Drum Rotary Dryer; Second is Normal Rotary Dryer
Rotary Dryer For Coal Powder Materials Application
1) Rotary Dryer For Coal Powder is suitable to dry metallic and nonmetallic mineral, clay in cement industry and coal slime in coal mine, etc.
2) Rotary Dryer For Coal Powder can be widely used to dry various materials and it is simple to be operated.
3) Rotary Dryer For Coal Powder is mainly used in building materials, metallurgy, and chemical industry, cement plant for drying of limestone slag, coal powder, slag, and clay stone.
Rotary Dryer For Coal Powder Structure
1) Rotary Dryer For Coal Powder is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.
2) Rotary Dryer For Coal Powder is mainly composed of shell, back and forth supporting wheel, feeding and discharging unit and gear cap. The accessories which are not in the the scope of this machine include firebox, feeding and discharging equipment, dust catcher, etc.
Rotary Dryer For Coal Powder Working Principle
Rotary Dryer For Coal Powder adopts direct flow type of heating with heat soure from firing unit. The material to be dried is pushed back immediately by spiral board when enters the shell from feeding tank and feeding chute. Because the drier is installed in slope, material flows to the back end under gravity and rotation force, meanwhile, it is lifted by board repeatedly and thrown down accordingly, which make the material form even curtain, and exchange heat sufficiently with inner the heat flow. In the end, water in the material is dried by repeatedly scattering.
Rotary Dryer For Coal Powder Main Technical Parameter
| Model(m) | Shell diameter(mm) | Shell length(mm) | Slope(°) | Rotary speed(r/min) | Weight(t) | Power(kW) | Volume(m³) |
| 0.6*8 | 600 | 8000 | 3-5 | 8 | 5.1 | 6-4 | 2.26 |
| 0.8*10 | 800 | 10000 | 3-5 | 7.2 | 6.9 | 6-4 | 5.02 |
| 1.0*1 | 1000 | 10000 | 3-5 | 6.73 | 7.5 | 6-5.5 | 7.85 |
| 1.2*12 | 1200 | 12000 | 3-5 | 5.8 | 13.1 | 6-11 | 13.31 |
| 1.5*12 | 1500 | 12000 | 3-5 | 4.8 | 22.3 | 6-15 | 21.2 |
| 2.2*14 | 2200 | 14000 | 3-5 | 3.2 | 52.8 | 30 | 53.22 |
| 2.4*18 | 2400 | 18000 | 3-5 | 3 | 73.3 | 37 | 81.43 |
| 2.8*24 | 2800 | 24000 | 3-5 | 2.59 | 97 | 75 | 147.8 |
Rotary Dryer For Coal Powder Display
Rotary Dryer For Coal Powder Warranty
1. Three-five Years (Calculated from the goods arrived the destination port.) If any parts (excluding easily damaging parts) are found defective in quality in the first year, we shall replace it free-of-cost. After one year, parts can be replaced on favorable payment basis.We can send our engineer to provide the installation and trial run in your place. But the relevant cost shall be bear in your account (round trip air ticket, board and lodging).
2. Our professional service includes: Free training, Guidance Installation and Debugging.
3. If you have any question, please contact us freely. Our after-sales service team on-line will do the best to accomplish your sincere requirement on time.
If you want to get more information of our product, pls link our website:
