Hot Sale Small Brick Machine

Hot Sale Small Brick Machine photo-1
US$ 1,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, small brick machine
Brick Raw Material:
Fly Ash
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, small brick machine
Brick Raw Material Fly Ash
Processing Brick Production Line
Method Hydraulic Pressure
Automatic Yes
Capacity according to the brick/block size
Place of Origin Henan, China
Brand Name Hongke Machinery
Model Number QT10-15
Voltage 380V/220V
Power 39 kw
Dimension(L*W*H) 5400*2600*2700
Certification ISO/BV
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

hot sale small brick machine



1. Introduction and Application of small brick machine

Brick machine is also called cement brick machine, hollow brick machine and baking-free brick machine, producing both wall bricks and pavement bricks.

2. Working Principle of small brick machine
This device Uses slag, fly ash, sand, gravel, cement and others as raw material, through the stirring in proportion and the molding under high pressure, to complete the brick making.

3. Features and Advantages of small brick machine

a.Not using the clay as raw material to destroy any field.



b.Making use of three industrial wastes to change wastes into valuables



c.Not using fire to bake blocks and not building kiln to save the energy sources and fields



d.No chimney to protect the environment and avoid pollution



e.The block can be produced all around the year

.

4. Technical parameters of small brick machine

Model

10-15

Overall dimension(mm)

5400*2600*2700

Cycle time(s)

15-20 seconds

Pallet size(mm)

1120*850*40

Weight(T)

13.8T

Power(kw)

39

Type

Specification

Block number/pellet

Block output/hrs

Standard block

240*115*53

48 pcs

92160

Hollow block

390*190*190

10 pcs

19200

Perforated block

240*115*90

24pcs

46080

Floor brick

200*100*60

30 pcs

5760

Remark. The brick size is just the regular size. The fact is that the size can be changed according to the customer’s requirement.

Besides, there are other models of brick making machine, such as DSQT8-15, DSQT6-15A, DSQT4-15, DSQT6-15B, DSQT4-20, and DSQT6-20, etc.



 hot sale small brick machine



Additional:

1. changealbe moulds: we can provide 3-4 sets of different kinds of moulds for your choice. Meanwile we could provide 1 moudls and 25 pallets for free.



2. best sale service: we could sent one professional man to your place for installation, as for the spare parts, we could provide you together with the host machine as well.



3. Since the shiping date of the products within one year, the damage or abnormal work due to the quality of the product, our company is responsible for repairing, changing and equipment lifelong maintenance for all our customers.



4. We will send the professional persons to the place of  the customer for equipment installation and program debugging,  and also for the production process and technology direction.



5. Pre-sale -  field investigation,  provide initial investment and technical consultation of factory building, formulate plan and feasibility analysis, etc







Applied Products: concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc





 hot sale small brick machine





if you are interested in our small brick machine, welcome to contact with me!



To service you better, please better confirm the following items:

1.what's raw material for making bricks?

2.what's the brick size(L*W*H)? if you have pictures, send me pictures please

3.what's the capacity(pcs/h)?

4.do you have budget on the brick machine you are looking for?



Take good advange of the wastes around you,using them, the small brick machine may bring you big profit!
