Full Automatic High effective foam concrete block cutting machine
Wire Cutting Machine is a new product in the foam concrete plant, It is specially used to cut various foam concrete blocks. Easy operation, high efficiency.
Main performance:
1- The lifting motor adopt the standard automatically brake motor.
2- Lifting speed could be adjusted through the frequency converter.
3- The block size between 100-200-300-400-500-600-700-800-900-1000-1100-1200mm could be adjusted willfully.
4- All motors are equipped with speed reducers.
GW 30B New Wire Cutting Machine is improved on the basis of the GW 30A wire cutting machine, It is specially used to cut various foam concrete blocks. Easy operation, high efficiency.
New wire cutting machine special performances:
1. Six shafts equipped with bearings, reduce the friction, and increase the rope wire lifetime.
2. Both horizontal and vertical cutting are cutting both way, keep the blocks more stable, and get good shape blocks.
3. Lifting speed could be also adjusted under the chain drive and lifting motor, more stable.
4. Two cutting motors equipped on the cutting frame, save space, and make the structure more impact.
5. Steel doors instead of the guard grids, more easy for daily maintenance.
6. Add cover on the top of the cutting machine, make the cutter elegant appearance.
7. Improved the control panel too, it is available for 380V/50HZ~460V/50HZ.
Technology data :
Name | GW 30B Wire Cutting Machine | ||
Electric Motor (Kw) |
| ||
Effective hoisting height | 800mm | ||
| 1300*1300*600mm | ||
Net cutting size (L*W*H) | 1200*1200*600mm | ||
Cutting cycle | 90-180seconds | ||
Overall dimension (L*W*H) | 2100*2050*2300mm | ||
Total weight | 1200kg |
COMMERCIAL TERMS:
1- GUARANTEE: 1YEAR
2- DELIVERY TIME: WITHIN ONE WEEK ONCE RECEIPT THE DEPOSIT
3- TERMS OF PAYMENT: T/T
4- SPARE PARTS: STEEL WIREROPE 1000M
Production Capacity | ||
0.8643M^3 | 600*200*75mm | 96 pcs/mould |
0.8643M^3 | 600*200*100mm | 72 pcs/mould |
0.8643M^3 | 600*200*150mm | 48 pcs/mould |
0.8643M^3 | 600*200*200mm | 36 pcs/mould |
0.8643M^3 | 600*200*300mm | 24 pcs/mould |
Our foam concrete block cutting machine at worksite:
Our PVC formwork :
The brick made by our Manual Brick Making Machine
Our manufactor shop :
Our cerfification :
If you have any question please feel free to contact me.
Gaode Equipment Co.,Ltd.
Tel:+86-371-55951210 Fax:+86-371-63526676
Skype: lena.liu8
Whatsapp&viber: 86-15903613994
Thank you for your time and Welcome to Visit our factory!
