GEC New Design GDD Series Slurry Pump for Wagon Drill

US$ 39,880 - 115,980 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

GEC

Model Number:

GDD

Contact Supplier Request Quote Chat Now

Zhengzhou Gaode Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name GEC

Model Number GDD

Theory Other, self-suction

Structure Other, plunger pump

Usage Other, trenchless drill field

Power Hydraulic

Standard or Nonstandard Standard

Fuel Diesel

Pressure High Pressure

Application Other, directional drilling

GEC New Design GDD Series Slurry Pump for Wagon Drill

Choose GEC, choose high quality!

GDD Series Slurry Pump for Wagon Drill

Slurry Pump for Wagon Drill Brief Introduction:

GDD series mud pumps use hydraulic power convert hydraulic energy into the drive that

can convey high pressure mud, self-priming piston pump, no rotating parts, piston linear

motion completely free.

GDD series mud pump can be used in all kinds of project, whether the high medium

is water or other medium.

Slurry Pump for Wagon Drill Production Features:

1. High reliability: no rotating parts, less moving parts, free maintenance time is long.

2. Excellent wear resistance and very high self-lubricating capability:

When the pump stops, let pump running to evacuate the medium, if so, prevent medium

in frozen in the pump, and protect the pump body, greatly reduces the operating costs.

3. When the input power less than the max. output power, GDD series mud pump can

automatically adjust the output power, and not damage to the trenchless rig hydraulic

system and the GDD mud pump.

4. High integration: small volume, light weight, work in the original hydraulic system, it takes

only very small installation space, (only need hydraulic pipe connect ).

Slurry Pump for Wagon Drill Application:

GDD Hydraulic Drive Trenchless Mud Pump uses hydraulic source of the machines to supply motive power, can be widely applied in Trenchless drilling field, such as Trenchless directional drill; Shield tunneling machine; Tube push bench; Rotary drilling rig; Wagon drill etc.

Slurry Pump for Wagon Drill Technical Specification:

Type	Output L/min	Pressure	Demension	Weight	Hydraulic System
Type	Output L/min	MPa	LWH mm	kg	Output (L/min)	Working pressure (Mpa)	Pressure(Mpa)
GDD45/5	45	5	518162381	45	20	12	21
GDD60/2	60	2	518162381	20	12	12	21
GDD160/6	160	6	518162589	80	50	20	21
GDD180/6	180	6	518169596	86	55	20	21
GDD250/6	250	6	542181606	96	80	20	21
GDD320/6	320	6	575235735	148	100	20	21
GDD450/6	450	6	575235755	152	135	20	21
GDD500/6	500	6	575235770	158	150	20	21
GDD600/10	600	10	1056450600	430	250	24	25
GDD1200/10	1200	10	1056500650	520	390	35	39
