Popular sales mini cellular lightweight concrete mixing machine
Operation principle:
The cement, fly ash(fine particle powder),etc. and water are mixed into cement paste in the mixing tank according to the proportion by MLC lightweight concrete special equipment, and press the cement paste into pipeline by hydraulic conveying cylinder; foaming agent mixed with water according to the proportion, then mixed with compressed air by high pressure pump, form fine foams of high density in the pipeline, and then mixed with cement paste in the pipeline,at last form MLC lightweight concrete.
Features:
1. Simple structure, small volume, light weight, easy operate,
2. According demands to choose suitable pumping speed.
3. Foaming system adjust frequency control speed, could adjust foaming agent ratio.
4. Mainly used for roof insulation, floor heating etc. projects;
5. High cost-performance.
Technical data:
Model |
GF10 |
Max.Output |
10m3/h |
Max.Conveying Pressure |
2 MPa |
Max.Horizontal Transporting Range |
200 m |
Max. Vertical Transporting Height |
70 m |
Acceptable Max. Aggregates size |
2 mm |
Power |
8KW |
Dimension |
1700x1150x1480mm |
Weight |
750kg |
1. Applied for insulating layer in floor heating constructions:the surface will flow smooth naturally and is an essential advanced equipment for floor heating construction.
2. Applied for roof insulation constructions: the foam material used in roof insulation is with warm keeping, heat insulating function, it’s effect is 20-30 times the ordinary material, which keeps the room temperature of top floor the same as other floors, warm in winter and cool in summer.
3. Can be used in producing various specifications of cement foam board, cement foam bricks and external wall insulation material.
4. Can be used in filling tunnel and mine internal voids, etc. And applied for insulation of low temperature cold store and refrigerated depot section.
5. Applied in freezing prevention and temperature maintenance of pipeline
