Foam concrete block making machine for clc foam concrete plant
The overall of the equipment :
New building material foam concrete block features:
*Low Cost *Light Weight
*Heat Preservation *Sound Insulation
*Fireproofing *Aseismatic
*High Construction Speed *Environmental Protection
GAODE clc block making machine for clc plant
1,Foam Concrete Mixer
2,Foam Concrete Pump
3,Foam Concrete Block Mould
4,Foam Concrete Block Cutting Machine
5,Foaming Machine
6,Foaming Agent
7,Foam Concrete Hardener
GM2000 Foam Concrete Mixing Machine :
1. The foam blending fast, blowing foam uniformly.
2. Without suspended matter, without the declining, it’s good for steady pouring.
3. Little loss ratio of foam maintain the foam proportion in the foam concrete to make the products with stability density.
4. No dead angle design, mixing the material toughly, storage in its bottom is less than 10mm, no material left on the four walls internal the mixing drum.
5. It could mixing variable materials, such as cement, fly ash, sand pulp, sand stone, perlite, and slag etc.
6. Variable speed mixing and internal structure alteration make its installation easy and mixing frequency high, it saves energy.
Technolog data (for clc plant):
| Model | GM2000 |
| Production Capacity | 15-20 m3/h |
| Output Volume | 1500 L |
| Material Input Volume | 2000 L |
| Main Shaft Revolution | 32 r/min |
| Hopper Lifting speed | 22 m/min |
| Mixing Motor | 11 kW |
| Winding Motor | 5.5 kW |
| Water Pump Motor | 1.1 kW |
| Vibrating Motor | 0.55 kW |
| Foaming System | 5.5 kW |
| Max. Moving Speed | 15 km/h |
| Total Weight | 3200 kg |
| Overall Dimension | 2600x2250x3000 mm |
GP30 Technolog data (for clc plant):
| Model | GP30 |
| Max.Output | 30 m^3/h |
| Max.Conveying Pressure | 8Mpa |
| Max.Horizontal Transporting Range | 600m |
| Max.Vertical Transporting Height | 200m |
| Max.Partice Size of Aggregates | 8mm |
| Cylinder Bore | 80mm |
| Delivery Cylinder Bore | 140mm |
| Max.Pressure of Hydraulic System | 24Mpa |
| Oil Pressure Box Volume | 200L |
| Motor Power | 30kw |
| Total Weight | 2200kg |
| Overall Dimension | 3100*920*1300mm |
| Dimension(mm) | 3900*1350*1450 |
| Overall weight(kg) | 1950 |
Our Brick cutting machine (for clc plant):
clc block making machine follows (for clc plant):
Worksite of clc block making machine:
Our Manufactor shop :of clc block making machine:
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
Delivery of clc block making machine :
Our other foam concrete machine :
Why Choose GEC Foam concrete machine ?
- Duplex full-hydraulic driven system to ensure high output pressure for high-rise construction
- Automatically control the proportion of the various components, density of foaming cement easy to be adjusted
- High-quality wear resistant components for long service-life and also provide after-sales service security ·installed with walk round, can move on the ground or mounted on the truck .
