Zhengzhou Gaode Equipment Co., Ltd.: Zhengzhou, Henan, China; Main products: peristaltic pump, grout pump, shotcrete machine, plaster machine, foam concrte machine

Home > Products > Concrete Equipment > China Supplier Hand Push Cement Concrete Curb Stone Slipform Paver

China Supplier Hand Push Cement Concrete Curb Stone Slipform Paver

FOB Price

US$ 1,500 - 2,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Paving Block Making Machine, Curb Stone slipform paver
Brick Raw Material	Other, cement, concrete, sand and etc.	Processing	Other, hand push curb stone slipform paver
Method	Autoclaved Aerated Concrete	Automatic	Yes
Capacity	1-2m/min	Place of Origin	Henan, China
Brand Name	GEC	Model Number	GDHM11
Voltage	No	Power	5.5Hp/3600rpm, 5.5Hp/3600rpm
Dimension(LWH)	15007201100mm	Certification	CE ISO or Other Certificate
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

The curb stone slipform paver is compact and easy to operate, screw extrudes the concrete to

make curbs, save time and effort, specially the the curb of the gardens. Parks, community and

flower bed.

Advantages:

1) With famous brand engine, reliable performance, easy to start-up.

2) With spiral feeding hopper, the counter force drives the machine backward walking.

3) With walking indicator to insure the correct direction.

4) Mold is easy to dismantle, and can be designed as per customer’s requirement.

5) Plastic treated, anti-rust and beautiful.

Datailed Images

China Supplier Hand Push Cement Concrete Curb Stone Slipform paver

Technical data

China Supplier Hand Push Cement Concrete Curb Stone Slipform Paver

Model	GDHM11
working
Working Type	Walk-behind Type
Work Speed	1-2m/min
Work Mold	As per customer’s requirement.
Engine
Gasoline Model	HONDA GX160
Gasoline Type	Gasoline engine, air cooling, 4 stroke, OHV, single cylinder.
Power	5.5Hp/3600rpm
Fuel Tank Volume	3.6L
Lubricant L	0.6L
Fuel Consumption	313g/kWh
Machine Size	15007201100mm
Package Size	1540790910mm
Weight	160kg

Application

China Supplier Hand Push Cement Concrete Curb Stone Slipform Paver

Zhengzhou Gaode Equipment Co., Ltd.: Contact nameJessica Liu
Chat Now; Phone86-371-55951210; AddressNo.9, Building 14, Yard No.4, Fengqing Road, Jinshui District, Zhengzhou, Henan China, Zhengzhou, Henan

Hydraulic Power Pack	Show Display	Screening sand machine	Road Marking Equipments
Rebar Thread Rolling Machine	Pipe Jacking Machine	Pile Driver	New Products
Mortar Plaster Machine	Industrial Pump	Air motor&Air winch	Garden Machinery
Foam concrete equipment	Filter Equipment	Environmental Protection Equipment	Drilling Equipment
Concrete&Refractory Shotcrete Equipment	Concrete Equipment	Brick Making Machine	Anchor Equipment & Tools

Model	GDHM21
working
Working Type	Walk-behind Type
Work Speed	2-3m/min
Work Mold	As per customer’s requirement.
Engine
Gasoline Model	HONDA GX390
Gasoline Type	Gasoline engine, air cooling, 4 stroke, single cylinder.
Power	13Hp/3600rpm
Fuel Tank Volume	6.5L
Lubricant L	1.12L
Fuel Consumption	313g/kWh
Machine Size	21701180970mm
Package Size	230010401200mm
Weight	690kg
