Choose GEC,choose high quality!
GDS1500G output 3m3/h mini shotcrete concrete pump with CE ISO
Description:
The GDS1500G is a gasoline-powered lightweight shotcrete pump run by a highly-reliable direct drive planetary gearbox and hydraulic power pack.
GDS1500G Shotcrete Pump sturdy workhorse is made better with the added improvement of a direct drive to the carousel.
The GDS1500G Direct Drive uses a Honda GX390 power pack, is skid mounted.
Features
1 highly-reliable direct drive planetary gearbox
2 infinite speed variation
3 Easily operating on site work
4 Standard spare part supply
Technical Data
Item | Description |
Working Pressure | 1.5 Mpa (Chinese Hose)/3.5 Mpa (Trelleborg Hose) |
Output | 1.5-3m3/h |
Max. Aggregate | 10mm |
The Squeeze Hose | ID 50mm |
Conveying Hose | ID 38mm |
Squeeze pump | GH50-455 |
Power | Honda GX390 Gasoline engine |
Overall Dimension | 1900x850x1250mm |
Hopper volume: | 200 Liter |
Oil tank | 120 Liter |
Weight | 610kg |
Requested air compressor | 3m3/min, 0.5Mpa Pressure |
Vertical Conveying Distance | 15 m (Chinese Hose)/30 m (Trelleborg Hose) |
Horizontal Conveying Distance | 40 m (Chinese Hose)/80 m (Trelleborg Hose) |
Note: the Diesel engine or Electric motor is optional.
A Complete set of GDS1500G shotcrete pump:
No. | Description | Qty. | Unit | Remarks |
1 | GDS1500main machine | 1 | set | |
2 | conveying hose, ID38, L10m | 1 | pcs | |
3 | Conveying hose, ID50, L10m | 1 | pcs | |
3 | reducer 2’’/1.5’’ | 1 | pcs | |
5 | 1.5’’shotcrete nozzle assy. | 1 | set | |
6 | 1.5’’nozzle tip | 1 | pcs | |
7 | clamp | 2 | sets | One set (one 1.5’’, one 2’’) |
8 | clean ball | 2 | sets | One set (one 1.5’’, one 2’’) |
9 | accessories | 1 | Set |
Hose pump, Honda GX390 Gasoline engine, Yuken flow control valve and air cooling:
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD78000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
Certification of our company:
We also can offer the concrete pump with diesel engine
GDS2000G:
GCP-20SR DIESEL CONCRETE PUMP:
GCP-15 CONCRETE PUMP:
