post tension Prestressed Concrete Electric Oil Pump
Specification of post tension Prestressed Concrete Electric Oil Pump
Descriptions:
1. ZB and YB series of Ultrahigh Pressure Pump is the sports nutrition of the jack, which is specially assort used with a variety of tonnage jack, upsetting and extruding machine top tensioning machine.
2. Type: ZB2×2/50A, ZB2×1.5/63, ZB4/80, YBZ2X2/50A, YBZ2X1.5/63A, and YBZ4/2-50B.
3. Pump is used for prestressing works
4. Pump is used for kinds of anchorage in railway, bridge and building construction
5. We can manufacture all kinds of anchor and equipment according to your requirement and drawings.
Applications:
It has been widely adopted by modern construction, especially used in pre-tension or post-tension for concrete constructions as building materials, such as bridge construction, railway and highway construction, buildings and channel construction, etc.
Features:
1. ZB and YB sseries high-voltage electric oil pump is high voltage, safety and high efficiency.
2. It can be matched with various prestressing equipment, and used in the different works with the oil pressure as power.
3. For example: matched with the suitable machines and devices, it can complete the elemental work such as propulsion, stretching, expansion, clamping, bending, jack-up, extrusion etc.
4. The engineer operation such as the crimping to conversion wire, rebar, reinforced concrete pile pilling, pile test etc.
5. The oil pump can install safety valve, relief valve and way directional control valve according to your requirement.
6. The oil pump is flexible to operate, convenient to use, safe and reliable.
Technical parameter for ZB series of post tension Prestressed Concrete Electric Oil Pump
Model | Rated pressure (Mpa) | Rated | Net weight (kg) | Power (KW) | Volume (L) | Overall | Purpose |
flow(L/min) | Model dimension(mm) | ||||||
ZB2×2/50A | 50 | 2×2 | 120 | 3 | 60 | 740×450×1050 | Used of various jack, extruder, button head with rated pressure less than 50 Mpa. |
ZB2×1.5/63 | 63 | 2×1.5 | 124 | 3 | 60 | 740×490×880 | Used of various jack, extruder, button head with rated pressure less than 63 Mpa. |
ZB4/80 | 80 | 4 | 270 | 4 | 60 | 1090×590×1120 | Have the performance of big flow, high pressure, can separately feed oil for two jacks. |
The technical for YB series of post tension Prestressed Concrete Electric Oil Pump
YB series of electric hydraulic oil pump | ||||
Model | Rated oil pressure | Rated flow | Power | Overall dimensions |
Mpa | L/min | KW | mm | |
YBZ2X2/50A | 50 | 2X2 | 3 | 740X450X820 |
YBZ2X1.5/63A | 63 | 2X1.5 | 3 | 740X450X820 |
YBZ4/2-50B | 50 | 4/2 | 3 | 810X550X950 |
YBZ2-2/50C | 50 | 2-2 | 3 | 740X450X820 |
YBZ10/4-50D | 50 | 10/4 | 3 | 800X500X960 |
post tension Prestressed Concrete Electric Oil Pump
we also manufacture anchors:
application of prestressing equipment:
post tension Prestressed Concrete Electric Oil Pump
Packaging Detail: standard export packaging; as your requirements
Shipping Detail: in stock; out of stock(5 working days); customized (7 working days)
post tension Prestressed Concrete Electric Oil Pump
we provide samples and after sale services. overseas services are available.
post tension Prestressed Concrete Electric Oil Pump
1. Specification
easy operation, good performance, reliable quality, hand operated and compact design
2. Application
used with large tonnage hydaulic jacks, anchorages, stirring and extruding machine, as well as top tensioning machine in post tensioning and prestressing work in railway,bridge and building construction.
post tension Prestressed Concrete Electric Oil Pump
Ware house
workshop
certificate
