HBT30-10D Hydraulic small diesel trailer-mounted concrete trailer pump
- 500 Set / Sets per Month
- Shaghai Qingdao Tianjin or as your request
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
CE Certification Concrete Pumping Placing Boom for Sale
-
Manufacturer Hydraulic Concrete Spreader Machine for Building Equipment
-
HBT40-11D pumpcrete machine and japan concrete pump for sale
-
2016 Hot Sale Concrete Placing Boom for Building Equipment
-
With Wire Control 28 Meters Concrete Placing Equipment for Construction
-
JS500II mobile self loading concrete mixer for sale
Product Details
| Condition | New | Power Type | Diesel | |
| Place of Origin | Henan, China | Brand Name | LEC | |
| Model Number | HBT30-10D | Power(W) | 46000 | |
| Weight | 3100KG | Dimension(L*W*H) | 4300*1670*1680mm | |
| Certification | CE , ISO | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HBT30-10D Hydraulic small diesel trailer-mounted concrete trailer pump
Brief introduction of concrete trailer pump and concrete pump :
In order to meet the demand of open country and other no power supply constructions, we research and developed the diesel engine concrete pump. Our concrete pump is set of mechanical, electrical and hydraulic technology as one, with reliable performance of smooth operation and strong pumping capability. The diesel engine is with advanced high quality, low emission, low fuel consumption, meet the advanced standard. Reliability and stability is guaranteed by automatic engine regulation.
The small model concrete pump is smaller, lighter and it is easier to be moved than the large model concrete pump.
Feathure of concrete trailer pump and small concrete pump for sale and concrete pump :
Intelligent power control system to regulate the engine speed automatically, for smooth and efficient operation
Plunger pump with constant power, to ensure the efficiency of main engine
Good sealing S-valve, installed with floating wear resistant ring
High-quality wear resistant alloy components for long service-life
High delivery pressure for demand of high-rise and long distance projects
Air cooling system, without dependence of external water
PLC system to ensure best control performance
With re-pumping function to smooth construction of better accessibility
Equipped with wired remote controller, easy to operate
Specification of concrete trailer pump and concrete pump :
Model No./Concrete pump | HBT30-10D |
Max. theoretical concrete pumping pressure (Mpa) | Low pressure 5.5 / high pressure 10 |
Max. theoretical concrete output (m³/h) | Low pressure30/ high pressure16 |
Theoretical vertical conveying height (m) | 130 |
Theoretical level transmission distance (m) | 350 |
Concrete tube conveying diameter (mm) and Max. Aggregate particles (mm) | Φ89 30mm Φ108 35mm |
Rated power (kw) | 46 |
Hopper volume (m³) | 0.45 |
Filling height (mm) | 1100 |
Hydraulic oil tank volume | 180L |
Diesel fuel tank volume | 90L |
Distributionvalve | S valve |
Overall dimension (L×W×H)(mm) | 4300*1670*1680 |
Total weight(kg) | 3100 |
Main Parts of concrete trailer pump and concrete pump :
Application of concrete trailer pump and small concrete pump for sale and concrete pump :
Conveying heating, heat insulation, light weight foam cement mortar.
Conveying light-weight foam cement, mortar for ground heating, heat insulation.
Conveying and injection of fireproof and heat preservation materials.
Press grouting and filling for all kinds of engineering and construction.
Mortar Pump
Placing booms
Packing: In Nude,One unit/20GP for concrete trailer pump
Delivery time: Usually in 10 working days for concrete trailer pump and small concrete pump.
Our Advantages and services for concrete trailer pump:
Factory directly supply.
Professional sales team and experienced workers.
Competitive price according to good raw material purchasing ability,and high work efficiency
Best manufacturer in China.
Good after-sales service
Spare Parts Supply Timely for concrete pump
Q1: What's the form of distribution valve for small concrete pump for sale
A: Its S valve.
Q2: What about the output you can supply?
A: The output we can supply is from 12CBM/hour to 80CBM/hour.
Q3:The matched pipes or hoses can't meet to our requirement, how can we want more pipes or hoses?
A: Easy, you could tell us before you book it, and we will calculate the cost of the extra ones.
Q4: If over the guarantee, we need spare parts, how?
A: Here, we are always here offer service in 24hours every day.
Q5: OEM or ODM is available about concrete mixer pump ?
Yes, we can produce with your logo.
Q5: How are concrete trailer pump products produced?
Refined manufacturing is the platform for a quality product.
Our concrete pumps equipment is built on a rolling assembly line, which streamlines efficiency and ensures a common build. The result is a consistent, quality product that doesn’t change with each production, simplifying things for you when it comes to maintaining your working site.
For more information about the small diesel trailer-mounted concrete trailer pump, please feel free to contact us.
