linear type bottle blowing machine
Equipment overview
This machine is the introduction of foreign advanced technology counterparts on the basis of the trend for domestic blowing equipment to high-speed, high-volume development, specially developed, developed. Mainly be used for pure water and mineral water PET bottle blowing. The machine has reasonable structure, small footprint, low power consumption, gas consumption, good stability, and many other advantages: and in line with national food hygiene standards in the domestic leading level, the device is ideal equipment for all types of domestic and medium -sized companies.
Main features of equipment
The whole operation with touch-screen operation, full Chinese display, production speed, shift production counting, fault type, etc. can be displayed on the screen. And automatic statistics failure time, fault type and other information, can achieve Man-machine dialogue;
• secondary blowing system specially designed to ensure the stability of the bottle molding quality, appropriate technology to meet customer standards;
• using four infrared heater thermostat control, digital automatic voltage regulator thermostat system;
• You can set the appropriate temperature according to different preform is heated, and the other contains a variety of bottle-shaped blown required packages;
• Equipped with automatic processing machines and preform billet hoist;
automatic linear type blowing machine Technical Parameters
Model |
SY-20 |
SY-40 |
SY-60 |
SY-80 |
Type |
Automatic |
Automatic |
Automatic |
Automatic |
Capacity |
2,000 pcs |
4,000 pcs |
6,000 pcs |
8,000 pcs |
PLC sys. |
SIEMENS |
SIEMENS |
SIEMENS |
SIEMENS |
Actuator sys. |
MITSUBISHI |
MITSUBISHI |
MITSUBISHI |
MITSUBISHI |
Operating system |
Touch screen |
Touch screen |
Touch screen |
Touch screen |
Power Sylinder |
SMC |
SMC |
SMC |
SMC |
Bottle size range |
Up to 2.5L |
Up to 2.5L |
Up to 2.5L |
Up to 2.5L |
Main motor |
40 kw |
60 kw |
60 kw |
80 kw |
Dimension(mm) |
2155×1750×2120 |
3280×1750×2200 |
5500×2200×2130 |
7280×3550×2200 |
Weight |
3.5 T |
5 T |
6.5 T |
10 T |
