SAW Wire EM12
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Red Copper Wire
Application:
welding various of structure steel
Wire Gauge:
2.0-5.0mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Red Copper Wire
Application
welding various of structure steel
Wire Gauge
2.0-5.0mm
Grade
Alloy steel
Alloy Or Not
Is Alloy
Place of Origin
Tianjin, China
Brand Name
XZ
Model Number
EM12
Specifications
Product:SAW Welding WireApplication:welding of general carbon steel structures
EM12 submerged arc welding wire
1)specification: EM12
2) Sizes: 2.0-5.0mm
3) Material applications
- Carbon steels (structural and vessel construction)
- Low alloy steels
- Stainless steels
- Nickel-based alloys
- Surfacing applications (wear-facing, build-up, and corrosion resistant overlay of steels)
Advantages
- High operating factors in mechanized applications.
- Deep weld penetration.
- Sound welds are readily made (with good process design and control).
- Minimal welding fume or arc light is emitted.
- Practically no edge preparation is necessary.
- The process is suitable for both indoor and outdoor works.
- Distortion is much less.
- Welds produced are sound, uniform, ductile, corrosion resistant and have good impact value.
- Single pass welds can be made in thick plates with normal equipment.
- The arc is always covered under a blanket of flux, thus there is no chance of spatter of weld.
4)Packing:
25kgs in coil per carton, 1ton in one pallet
250kg with drum packing
Chemical Composition of the Welding Wires(%) | ||||||
C |
Mn |
Si |
Cr |
Ni |
S |
P |
≤0.10 |
0.8~1.1 |
≤0.07 |
≤0.20 |
≤0.30 |
≤0.030 |
≤0.030 |
| Mechanical Properties of Welding Wires | |||
σ b |
σs |
δ5 |
Akv |
415~550MPa |
≥330MPa |
≥22% |
≥27J |
