Manufacturer flux solid welding wire tungsten carbide dies diamond die drawing die
drawing die
The wire drawing die/mould is a kind of mould that can get the shape and size required
for the cross-sectional area to reduce the cross
sectional area of metal by pulling metal through the mould under the external forces
in metal working process.
Wire |
Hard lines |
Soft lines |
|
|||
| ||||||
Part Names |
Stainless steel |
Copper Clad Steel |
Tungsten, molybdenum |
Copper |
Aluminum |
|
| ||||||
Entrance |
80° |
80° |
80° |
80° |
80° |
|
Lubrication angle |
35° |
35° |
35° |
35° |
35° |
|
Compression angle |
14°±2° |
14°±2° |
14°±2° |
14°±2° |
14°±2° |
|
Parallel to the District |
0.2D~0.5D |
0.2D~0.6D |
0.2D~0.8D |
0.2D~0.5D |
0.2D~0.5D |
|
Decompression angle |
25°±5° |
25°±5° |
25°±5° |
25°±5° |
25°±5° |
|
Export |
60° |
60° |
60° |
60° |
60° |
|
Our PCD wire drawing die adopts advanced material and technology. It can replace
natural diamond mold. The result of using is much better than natural diamond. Our
PCD wire drawing die has such characteristics: hardness, high wear resistance & thermal conductivity and high mechanical strength and tenacity.
The wire drawing die/mould is used widely, for example, high precision wire materials u sed in electron device, radar, television, instrument and aerospace etc., and common t ungsten wire, molybdenum wire, stainless steel wire, electric wire and cable, and vario us alloy wire . Because of the raw material of wire drawing die/mould adopted the natur al diamond or synthetic diamonds, it has good wear resistance with long service life.
drawing die
Wooden cases
Xuzhi company product scope:
1, Flux cored wire plant project Consulting (including the new factory process design,
old factories technology and equipment reform, improve the production efficiency, the new product formula design and development.)
2, Flux cored wire complete line manufacturing
3, Hardfacing & stainless steel etc special flux cored wire product manufacture
4, Provide high quality 2roll-type and 3roll-type of roller die cassette for the following
types of customers:
flux cored wire manufacturer
solid wire manufacturer
rebar manufacturer
5, Produce various specifications and types of wire drawing machines used in
metal products processing and manufacturing
6, Metal products finished product cleaning machine (such as: steel strip cleaning, machinery parts cleaning, glasses cleaning, and more complex shape metal products finished product cleaning)
7, Metal products auxiliary machine manufacturing (such as: various types of pointing machine,V-type powder mixer,strip slitting machine,argon arc wire butt welder,wire
winding machine,drum packaging machine)
8, Potato chips production line
9, Napkin paper productuon line
drawing die
Xuzhi company was founded in 1998. After years of development, now the company already had the mainstream business which shows in the next item.
Except the mother company “xuzhi company”, we have other companies were built according to professional led division, intensive management framework. At present the company development direction is to professional industry chain deep direction. Thus be dedicated to research and development, design.Now TIANJIN THREE WATER is the export company serviced for xuzhi.
drawing die
