JTRRG Emulsification Tank
Emulsification Tank be designed, manufactured and inspected in accordance with the pressure vessel standard (GB150-2011) and the steel welded atmospheric pressure vessel standard (NB/T 47003.1 -2009) , strictly meet to GMP certificate requirements.
Emulsification tank is used to mix one or several materials (water soluble solid, liquid or jelly) with a other liquid and then to hydrate it into Emulsion liquid
“Jhenten” homogenization agitator can apply together with Center blade agitator and scraped suface agitator. That is the best agitator combination. The Emulsification Tank adopts Vertical circular design with dimple jacket, coil jacket and full jacket both for cooling and heating. The tilting bottom design is well for emptying. There are 316L and 304 stainless material for choosing.
Tank Optional Configuration
Reactor can configure aseptic air filter, thermometer (Digital display or Dial type), PH meter, pressure gauge, steam sterilization hole, sight glasses, sanitary manhole, liquid in-outlet, CIP cleaning ball, liquidometer and Liquid level control system(Bearing module, non-contact ultrasonic, static pressure transmitting device) and so on, also can configure as customers’ requirement.
Feature
Impact structure, small volume, Light weight, easy operation, low noise, stable operation. The biggest features: no grinding materials and combination of shearing at high speed, mixing, dispersion and homogenization.
• Reasonable ratio of diameter to height, energy-saving, fast mixing of materials, high efficacy of emulsification and homogenization.
•The inside wall is processed by electrolytic mirror polishing or mechanical polishing , and the outside wall adopts 304 full welded insulation structure. The outside surface is processed by mirror polishing or matting polishing. Opening techniques of all inlets outlets, sight glass and man hole and welding joints in tank use the flanging process of arc transition.
Easy to clean, stable in production, meeting the GMP standard..
•Volume:600L~20000L and multiple specification, also can design and manufacture according to customers’ requirement.
Application
Suitable for cosmetic, medicine, food, chemical, dyeing, printing ink and other industrial production, especially for high matrix viscosity, solid material content higher material preparation emulsion will be more efficacy.
Emulsification Tank can configure 0.2μm hydrophobic sterile air filter, thermometer (Digital display or Dial type), 2 sight glasses, steam sterilization hole, sanitary manhole, liquid in-outlet, CIP rotating cleaning ball, liquidometer and Liquid level control system(Bearing module, non-contact ultrasonic, static pressure transmitting device) and so on, also can configure as customers’ requirement.
