JTRPG Mixing Tank
JTRPG Mixing Tank is designed, manufactured and inspected in accordance with the pressure vessel standard(GB150-2011) and the steel welded atmospheric pressure vessel standard(NB/T 47003.12009) ,
strictly meeting GMP certificate requirements.
The mixing tank is a vertical tank in which the agitator mixes the material to meet to the technical standard.
The Mixing Tank adopts vertical circular tanks, both of top and bottom are standard oval and torispherical head. Transition section in tank uses circular arc transition, without dead corner, easy to clean. Single layer, double layer(insulation for tank and bottom head) or Jacket(tank and bottom head have jacket and insulation) is equipped with mechanical stirring according to customers’ requirement.
Tank Optional Configuration
The Mixing Tank can configure aseptic air filter, thermometer(Digital display or Dial type), PH meter, pressure gauge, steam sterilization hole, sight glasses, sanitary manhole, liquid in-outlet, CIP cleaning ball, liquidometer and Liquid level control system(Bearing module, non-contact ultrasonic, static pressure transmitting device) and so on, also can be configured as customers’ requirement.
Feature
• Volume:100L~5000L and multiple specification, also can design and manufacture according to customers’ requirement.
•Jacket can pass steam (or hot water), can also pass the cooling water. There are full type jacket,half-pipe coil jacket, dimple jacket and plate coil jacket. Jacket outside is covered with insulation, thermal insulation material for rock wool (warm) or PU (cold).
•The connection adopts Tri-clamp, and the tanks’ inner layer use 304 or 316L. The inner surface mirror polishing Ra≤0.28μm~0.6μm. Outer surface can be polished, wire drawn and sand blasted according to customers’ requirement.
• According to the requirements of production and processing, it can be designed with low heating, cooling, high-speed mixing system, sealing pressure system, vacuum system, measuring system and so on.
•According to different mixing materials and requirements to the mixing effect, the structure of impeller can be the turbine type, paddle, anchor type, frame type, screw conveyor and so on.
