Lenticular Filter Housing
Brief introduction
Lenticular filters have a long history in Food and Beverage applications, They arose out of the need to package sheet-based depth filter technology in more user-friendly, modular closed systems, especially for small batch production or medium flow rate applications.Jhenten's lenticular filter housing can be suitable for international brand 's filter disk with lower cost.The surface finish totally arrive sanitary grade requirement.
Operating Parameters
Max Operate pressure: 1.0 MPa
Max Operate temperature: 110ºC
Industrial sure tolerance on weld : 0.85
Corrosion by acid 0 mm
Features:Lenticular Filter Housing
• Versions available in high-grade AISI 304 and 316 L stainless steel
• 150PSI rated and up to 300ºF
• This apparatus was manufactured and tested under the standard of GB150-1998,
This apparatus meet GMP standard
•All wled-seam are argon are welded
• Hygienic design by avoiding dead space, Sanitary Filter Housing, No Dead Corner
•All surfaces that come in contact with the product are mirror polish or electro polished, Ra< 0.4 µm
• 1.5" Pressure Gauge Ports,1”Drain,1/4" air Vent"
Applications
Wine
Food &Beverage
Process Water
Pharmaceutical Liquids
Biotechnology & Laboratory
Medical &Medical Device
Chemical And Painting
WENZHOU JHENTEN MACHINERY CO.,LTD
A Professional Manufacturer of Filter Housing
