fruit puree / fruit paste batch pasteurizer operated by electric
1. electric heating pasteurizer
2. batch pasteurizer in 300L capacity
Product requested: stainless steel pasteurizer
Request in detail: pasteurizer heated by electric,
used to pasteurizer milk to 85degree C and then cooling to 40degree C
fruit puree / fruit paste batch pasteurizer
The cooling system may be water and the heating may be propane gas
Heat milk to 180F and then cool to 100F
gas heating pasteurizer specificaton
Specification of the above gas heating pasteurizer
Capacity | 300L |
Working Pressure | 0.09 MPa |
Test Pressure | 0.15 MPa |
Stirring Speed | 36 r/minor customized |
Agitator type | Anchor type with scraper |
Motor power | 0.55kw |
Heating Area | 1.6 m² |
Material in/outlet | Φ32 |
Heating method | Electric heating |
Gas burner position | Bottom of the reactor |
Temperature gauge | 0°C to 150 °C |
Working temperature | ≤100 °C |
Temperature control | Automatic control |
Overall Dimension | Φ*00×*000 |
|
|
fruit puree / fruit paste batch pasteurizer
batch pasteurizer 300L pasteurizer fresh milk
In this solution, you will us the pasteurizer structure as above mentioned, you will need to put heating transfer oil into the gap or jacketed. Heating transfer oil will help you get 80 degree milk in shorter time than water heating type pasteurizer. This heating process can be controlled automatically.
After milk arrived at 80 degree, you need to put open the milk pump to send milk from the pasteurizer to a plate heat exchanger. In this plate heat exchanger, hot milk will exchange heat with cooling water.
This cooling process cannot be controlled automatically.
Here is the picture of the related juice puree pasteurizer and the accessories.
Before you turn on the heating button, you put heating oil to the gap first and then turn on your gas and start to heating. Gas will boil the water in the gap and the heat from the high temperature oil will send to the milk in the pasteurizer.
usage of batch pasteurizer: used to pasteurize fresh milk, fruit juice, fruit pulp, fruit puree, fruit paste
When milk temp arrived at the right temperature range you need, you can stop the heating process and access cooling water to the gap and allowed the water run freely through the gap.
Close the water until the temperature gauge shows the right temp you need.
Picture of the mentioned electric hating batch pasteurizer
best price batch pasteurizer on sale with automatic temperature control
