Stainless Steel Water storageTanks
stainless steel mixing storage tank / Cone & Flat Bottom Mixing soag Tanks
for Chemical and juice
A mixing tank is a container that is used to blend several components together. The material that a mixing tank is made of can range from stainless steel 304, SUS 316, or steel of all types. Stainless steel is often used in the creation of a mixing tank due to the ease of clean-up as well as the smooth surface of the product. We use SS304 and SS316 in the making of a our mixing tank;
In most manufacturing facilities, the use of a stainless steel mixing tank to prepare materials that will be used in production is common. Large containers of raw materials are placed into a large stainless steel mixing tank and are blended into a smooth mix that can be used to produce a plethora of materials. In a bakery environment, a stainless steel mixing tank might contain flour, yeast and water, all of which were taken in specific amounts from smaller bins and placed into the larger tank to be mixed.
The stainless steel welder is often schooled in many types of welding processes. When asked to create a stainless steel storage tank, the welder is required to actually get inside of the tank to weld the internal seams of the tank, so welders in this profession cannot have issues with being in an enclosed area.
Corrugated stainless steel tubing may also be found in laboratory and research settings, as well as industrial and manufacturing facilities.
Cone & Flat Bottom HDPE Mix Tanks 30-8000 Gallon Tanks, VFD Mixers
Our Mixing Tank line handles batch sizes from 200L to 10000L or 30-8,000 usable gallons, while still offering larger, and smaller, custom sizes to fit any requirements.
Our stainless steel mixing tanks are designed with quick and easy set-up, these high density polyethylene (HDPE) resin mixer scrapers supports provide years of maintenance free service.
Our mixers feature crucial components from world famous brand motors. Variable Frequency Drives (VFD) are added according to customer request, allowing full control of motor speed, and adjusting for varying viscosities.
All wetted mixer parts are SS304 or SS316 Stainless Steel.
These kind of mixing tanks can be conical bottom or flat bottom, with manhole/close top tanks, or open top with lids type.
Here below is the detail of the hot sell tanks
| mixing tank capacity | 400L | 500L | 600L | 800L | 1000L | 1500L | 2000L | |
| working pressure | 0.09MPa | |||||||
| test pressure | 0.15MPa | |||||||
| mixer speed | 36r/min | |||||||
| heating area<m²> | 1.6 | 2 | 2.5 | 3.5 | 4.5 | 6.5 | 7.5 | |
| material inlet DN | 40 | 40 | 40 | 40 | 40 | 40 | 40 | |
| heating power (KW) | 8+ | 10+ | 10+ | 12+ | 12+ | 12+ | 14+ | |
| mixing tank dimension | Φ1300×1800 | Φ1350×1900 | Φ1350×2000 | Φ1400×2000 | Φ1600×2200 | Φ1750×2300 | Φ1900×2500 | |
| weight(Kg) | 680 | 720 | 760 | 800 | >980 | 1020 | 1100 | |
