Specifications
Stainless steel liquid storage tanks1.Material: SUS304 or SUS316
2.to Storage liquid,food drinks
3.With jacket for cooling
Applicable range:
1. Common large outdoor dairy storage equipment in arge and medium dairy processing enterprises.
2. In industries such as fruit juice and pharmacy etc.
Stucture caracteristics
1. Adopt structure of internal tank and external package, with heat preservation materials inside.
2. Miller board jacket cooling design for keeping freshness and quality of dairy products.
3. Humanized design of door hole and easy to operate.
4. Transition aarea of interior wall on tank adopts arc for transition to ensure no dead conor of sanitation.
Technical parameters
Nominal volume | The total height of the tank | Shell height | External diameter of the barrel | Discharging height |
500L | 1725 | 800 | 850 | 350 |
1000L | 1950 | 900 | 1100 | 350 |
2000L | 2500 | 1300 | 1300 | 400 |
3000L | 2800 | 1500 | 1500 | 400 |
5000L | 3100 | 1650 | 1800 | 400 |
6000L | 3350 | 1800 | 1900 | 450 |
8000L | 3600 | 1950 | 2100 | 450 |
10000L | 3800 | 2000 | 2300 | 500 |
20000L | 5350 | 3400 | 2600 | 500 |
