Specifications
1.CE&ISO9001
2. Low speed running and energy saving
3. Easy to install and disassemble
4. Could choose PLC,HMI,touch scree
stainless steel electric heating Reactor with agitation
Feature of heating reactor:
The equipment is mainly used for the production chains such as hydrolysis, neutralization, crystallization, distillation, evaporation and storage in the industries of medicine, chemical, food and light industry etc. The reaction kettles are made of SUS304, SUS321, SUS304L and SUS316L etc.
1.The mixers are divided into anchor type, frame type, oar type and turbo type etc.
2.The rotation mechanism can adopt cycloid pin gear reducer and stepless speed reducer .
3.The sealing mechanism can adopt mechanical sealing.
4.The heating and cooling can adopt jacket, semicanal and coil structure etc.
5.The heating methods are steam, electric and HTF (Heat transfer oil) to satisfy the technology requirements under different work environment such as anti-acid, anti-high-temperature, anti-abrasion and anti-corrosion.
The design and manufacturing can be carried out according to the requirements of customer’s technology.
Main Data of heating reactor :
Volume(L) | Heating Power(kw) | Inner tank diameter(mm) | Jacket diameter(mm) | Reducer Model | Engine Power n/kw | Mixing speed r.p.m |
50 | 4x2 kw | 400 | 600 | BLD 0.8-1 | 1450/0.8 | 60-100 |
100 | 6x2 kw | 500 | 700 | BLD 1.1-1 | 1450/1.1 | 60-100 |
300 | 6x4 kw | 800 | 1000 | BLD 2.2-2 | 1450/2.2 | 60-100 |
500 | 9x4 kw | 900 | 1100 | BLD 3-2 | 1450/3 | 60-100 |
1000 | 12x4 kw | 1200 | 1400 | BLD 4-3 | 1450/4 | 36-100 |
2000 | 12x5 kw | 1400 | 1600 | BLD 4-3 | 1450/4 | 36-100 |
3000 | 15x5 kw | 1600 | 1800 | BLD 5.5-3 | 1450/5.5 | 36-100 |
5000 | 18x5 kw | 1700 | 1900 | BLD 7.5-4 | 1450/7.5 | 36-100 |
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
