1.Application: Adhesive,Polyester Resin,Coating,Additive,Dye,Paint
Medicine,building materials,pigments,resin etc
2.Heating method: Electric heating / Steam Heating or Thermal Oil Heating
3.Model: Jacketed Reactor or Limpet Coil Reactor.
4.Material: SS304/316,Jacket/ Carbon steel.
5.Agitator: Paddle Agitator, Anchor agitator, Frame agitator.
6.Advantage: rapid heating, high tempature resistance , corrosion resistance,sanitary,pollution-free, automatic heating without boiler and easy usage.
PS:The table and pictures are as follows:
model | nominal capacity L | Actual capacity L | Heating powerKW*strip | Oil clip of capacityL | Inner pot size Dmm | Jacket size D1mm | Bearing screw holes center D2mm | Stirring speed | Weight kg |
50L | 50 | 78 | 2*4 | 96 | Ø400 | Ø600 | Ø828 | 85 | 4-25 |
100L | 100 | 127 | 2*6 | 127 | Ø500 | Ø700 | Ø928 | 85 | 4-25 |
300L | 300 | 327 | 4*6 | 218 | Ø800 | Ø1000 | Ø1148 | 85 | 4-25 |
500L | 500 | 509 | 4*9 | 269 | Ø900 | Ø1100 | Ø1252 | 85 | 4-25 |
1000L | 1000 | 1017 | 4*12 | 400 | Ø1200 | Ø1400 | Ø1588 | 85 | 4-30 |
2000L | 2000 | 2154 | 4*15 | 850 | Ø1400 | Ø1600 | Ø1840 | 85 | 4-30 |
3000L | 3000 | 3201 | 5*15 | 1015 | Ø1600 | Ø1750 | Ø2040 | 85 | 4-35 |
4000L | 4000 | 4020 | 5*15 | 1226 | Ø1600 | Ø1750 | Ø2070 | 85 | 4-36 |
5000L | 5000 | 5170 | 5*18 | 1400 | Ø1800 | Ø2000 | Ø2320 |
The structure of the reaction kettle, high and low pressure, heating mode,agitator forms can design and manufacture according to customer's technical conditions.The selection of materials is according to customer needs, manufacturing all kinds of stainless steel, titanium, nickel and carbon steel reactor, reaction tower, reaction tank, condenser, heat exchanger, storage tanks etc., as well as non-standard chemical equipment.Producing magnetic coupling with the reaction tank,and matched size according to customer's technical conditions.Our productshave been standardization,seriation after a process of more than ten years of development and continuous improvement,innovation.The reasonable design,complete specifications,easy operate, can satisfy the most needs of all walks of production and scientific experiment.Our company relies on strong technical force, according to user's special process for special design and production, to meet the special needs of users.Products sold throughout the country, favored by the majority of users' trust and praise.
Note:Design and manufacturing in line with the national I grade,II grade pressure vessel manufacturing
1,Reply your enquiry in 24 working hours.
2,Experienced staffs answer all your questios in professional and fluent English.
3,Customized design is available.
4,Exclusive and unique solution can be provided to our customer by your our well-trained and professional engineers staffs
About Delivery time
Q-----What’s the delivery term for making business with us?
A----- FOB, CFR & CIF optional; It’s mainly depend on client’s requirement;
About Lead Time
Q------What’s the lead time after placing order?
A------Usually it takes about 25~30 days after we received your deposit.
However, it would depend on our production line schedule(the timing clients place order)and
the complication of the item.
About Payment Term
Q------What’s the Payment Term?
A------ By T/T, or irrevocable L/C at Sight.
Our equipments can be customized, leave an inquiry to know more details about price, packing, shipping and price.
Send your message to following supplier :
ØPackaging & Shipping:
Plywood case packing.
1. PE film wrapping for inner.
2. Separate PE bag for fittings .
3. Synthetic fiber paper for corners to avoid possible scratch.
4.Carbon steel transport frame for Large Unit
Shipping by sea. Accept terms: FOB, CIF, C&F, etc.
