Help Center1000 Liter Milk Cooling Tank
Related Products
-
500L-1000 Liter Stainless Steel Vertical Milk Cooling TankUS$ 2,800 - 8,000MOQ: 1 Set -
Direct Milk Cooling TankUS$ 2,800 - 8,000MOQ: 1 Set
-
Milk Direct Chilling TankUS$ 500 - 5,000MOQ: 1 Set
-
Direct-cooling Type Milk Store Tank(for Keeping Milk Fresh)US$ 500 - 5,000MOQ: 1 Set
-
Small Milk Processing Plant / Mini Dairy PlantUS$ 33,500 - 33,846MOQ: 1 Set
Specifications
Milk chilling&Receiving unit
(1)Evaporation board struction
(2)minimum consumption of energy
(3)super efficient churning up
Company Information
We are professional manufacturer for food&beverage processing equipment. We have been working in this field for several years.
DAFENG milk cooling tank is mainly used in preserving and storing fresh milk. It fully adopts the international advanced technology with the imported European Maneurop (non-fluorine) and safety protection system.
Product Description
Specifications
Capacity 5000 - 10 000 liters
Geometry - full cylindrical horizontal (high capacity) and vertical (low capacity)
Cooling temperature - 35C down to 4C
Cooling tank body material - SUS 304 stainless steel
Double wall
Stainless steel Rollbond evaporator
Perfect isolation with polyuerthane
Digital thermometer
The name of equipment: milk cooling tank
Usage:cooling and storing milk or other liquid
Cooling temperature,35C down to 4C Cooling tank body material - SUS304,stainless steel Rollbond evaporator,Double wall, isolated.
Usage Overall Milk direct cooling tank is suitable for pasture and cooling storage of the just come out fresh milk or goat's
milk, also can use at the small milk collection station, dairy factory and the storage and cooling of the food, feed, medicines liquid materials factory
Structure
Integral cooling machine mainly consist of several major components of tanks, mixer, refrigeration unit, electric control
box, pump, the material vat etc. Tanks are all made of stainless steel, precision polishing, dirt not easily stored up,
corrosion resistant, easy to clean.
Advantages 1.The thermal insulation layer use small coefficient of thermal conductivity of rigid foam filling, light quality, heat preservation performance is reliable.
Straight wall large cooling area, by specifying automatic microcomputer control system, one pace reachs the designated position for observation operation,
cause the cold milk quickly dropped to the required temperature of 4 °C and renewal constant temperature, prevent bacteria growth and keep the original milk
in A grade A milk state!
2.Cooling compressor unit selects the high performance, energy-saving of Tecumseh European company or Corpland of the United States produced as the
totally enclosed compressors, equipped with reliable midpoint protector, not easy to damage the compressor.Insulation layer
adopts polyurethane foam new craft, insulation performance is good.Tank made of stainless steel SUS304, with automatic
cleaning device and mixing device.
Installation Refrigeration can of convenient installation, have been adjusted before leaving factory, cooling tank using just by turning
on the power supply.If the ground uneven can use the adjustable support bolts, helps to balance tanks.
Technical parameter
Model |
Normal Volume (L) |
Tank Body |
Agitator Motor (kW) |
Agitator Returning Speed (r/min) |
|||
Length (mm) |
Width (mm) |
High (mm) |
Weight (Kg) |
||||
-500 |
500 |
1360 |
1060 |
1360 |
510 |
0.75 |
25 |
-1 |
1000 |
1760 |
1260 |
1510 |
640 |
1.1 |
36 |
-2 |
2000 |
2000 |
1660 |
1800 |
880 |
1.1 |
36 |
-3 |
3000 |
2210 |
1860 |
1960 |
1120 |
1.1 |
36 |
-4 |
5000 |
3060 |
2015 |
2100 |
1620 |
1.1X2 |
41 |
-5 |
8000 |
3260 |
2060 |
2200 |
1740 |
1.1X2 |
41 |
-8 |
10000 |
2950 |
2300 |
2500 |
2170 |
1.1X2 |
41 |
Photos
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
