Fermentation Tank
- ningbo
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | dafeng | Model Number | BE-2 | |
| Processing Types | Alcohol | Voltage | 220/380 volt 50/60 Hz, 380V/3phases | |
| Power(W) | customized | Dimension(L*W*H) | can be adjusted | |
| Weight | customized | Certification | CE&ISO | |
| Warranty | 2 year |
Product Description
Fermentation Tank


The fermenter iswidely used in such industries as brewing, dairy product processing, etc... The
conical fermenter is a beautifuldesigned product for the discriminating brewer. Its features
provide commercial brewery functionality at a consumer good price. It is easy to use and loaded
with standard features.
Features of conical Fermenting Equipment| Inner surface | S.S.304,WELL POLISHED,polishing precision≤0.4µm,THK:2-4mm |
| Outside surface | S.S.304,frosted or mirror,THK:1.5-3mm |
| Top shape | Seal head or conical head |
| Conical degree | 60-90°c |
| Manhole location | Side upward/side/flanged |
| Insulation | Material:PU,THK:50-100mm |
| Cooling jackets | DIMPLED cooling jackets at bottom and side wall. |
| Spray ball | Located in the center of inside of the tank |
| Pressure | 0.2MPa |
| Thermometer | Bi-metal thermometer |
| Legs | 3/4 round legs,can designed to be adjustable |
| The ratio of working volume to gross volume | 4/5 |
| Operational method | Automatic or manual |
| Technology processing | Argon-arc welding,well weld in double sides. |
1. The tank body has interlayer and heat-insulating layer (for heating, cooling or heat insulating)
The tank body, upper and lower closure heads(or taper) all adopt spinning R-angle processing.
The internal wall of the tank has got mirror polishing with finish Ra≤0.4μm.
2. It has no sanitary dead corner and its wholly-enclosed design ensures that materials are always
mixed and ferment at non-pollution state.
3. Aseptic system helps avoid microorganism pollution in the air and greatly extends quality
warranty period and purity of the products. We specially designed and installed aseptic
respiratory air hole or aseptic normal-pressure fermentation system, which can finish circulating
heat-up and cooling through medium heat-up.
4. The parts that contact materials are all made of stainless steel SUS304 or SUS316L. Heat
preservation adopts polyurethane blister or pearl cotton. External surface adopts sand grinding
surface polishing treatment. All is in accordance with GMP standard. Volume has different
specifications ranging from 100-50000L.
1.PRODUCTION INFORMATION
| Description of goods | BEER FERMENTATION |
| Capacity | customized |
| MOQ | 1 PC,THE MORE THE CHEAPER |
| Lead time | 30 days,based on your demand |
| Packaging | exporting standard wooden case,up to you. |
| Payment | T/T,L/C, Western Union |
| Supplying ability | More than 500 pcs per year,based on the capacity |
| Port of loading | NINGBO |
| Trade term | FOB,CIF |
| Material | FOOD GRADE S.S.304 |


Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
