ZBC-W series High-efficiency poreless filmcoating machine
- 200 Set / Sets per Month
- Ningbo
- T/T Credit Card
- China Rotary Desktop Tablet Pill Tablet Octagonal Small Sugar Film Mini Sugar Coating Pan Machine
- Honeycomb Coating Pan Desktop Peanut Cashew Nut Chocolate Mini Automatic Tablet Coating Machine Pills to Mix
- High Quality Sugar Cashew Nuts Chocolate Tablet Panner Small Candy Pharmaceutical Tablet Coating Pan Machine
- Peanut Tablet Polishing Pecan Sugar Pearls Coating Pan Gummies Sugar High Efficiency Coating Machine
- Gummy Candy Medicine Sugar Mini Chocolate Tablet Film Coating Machine Auto Coating Pan for Rice Cakes
- Pharmaceutical Tablet Pill Almond Peanut Candy Tablet Coating Pan Dragee Sugar Coating Machine
Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | DF |
Model Number: | HIC( High-efficiency Intelligent Coating Machine) | Usage: | Pharmaceutical |
Product Description
Coating Machine ,it can be widely used for coating Various tablet pills and sweets with organic film,water-soluble film etc.
Usage
The ZBG-W series high-efficiency pore less film coating machine is a high-efficiency energy-saving safe clean computer-controlled and mechatro nics equipment which is used for coating sugar organic film water soluble film slow and controlled release film on traditional Chinese and western tablets and pills(including micro pills small smell pills water-bindered pills drip pills and granulated pills) and conforms to the requirement of GMP it is a high-tech product first successfully developed in china by this factory.
Working principle
The tablet cores(micro pills small pills or plain tablets) to be film coated make continuous complicated orbital motion a closed rotating drum under the action of a streamline guide plate controlled by computer and according to the optimum technological parameters they are automatically sprayed with filmcoating medium while hot air under a negative pressure is led in from one side of the air distributing pipe by a pore duckbill-shaped(or oval air paddle embedded in the tablet core layers so that the film coating medium medium sprayed on the surface of tablet cores will dry rapidly and evenly there by forming a layer of solid compact neat smooth surface film.
(1).Automatic open and close side door device. More convenient and relax to clean and adjust the large cabinet to coat small pills.
(2).whole sealed structure. Good sealing performance. Beautiful and elegant.
(3).Automatically charging and discharging. Simply operation.
(4).Cleaning in place automatically control pressure. And reduce cross pollution.
3. Main Structure
(1).The major machine during the film coating process in the major machine .it shows such features as no dust fly off, no syrup splash. Operation condition improves, little cross contamination to tablets. simple coating process, coating time shortening as well as high production efficiency etc.
there adopted a new &mini-type computer and a touch screen control system are displayed with such functions as programmability, automatic adjusting such a majority of process parameters as air flow. negative pressure. Intake exhaust. temperature. Rotational velocity etc. making the compile of sop digitalizing. Making no difference between various batches of products with the figures of mediums density. Instantaneous flow and total flow amounts can be displayed and controlled.
(2).Hot Air cabinet firstly, air inhaled in through centrifugal fan should be purified up to the 100,100 level after three times filtration involving primary the main machine through the heat exchanger (steam or electro thermal).finally, be blown to the drum of main machine to dry the tablets, the noise of which less than 70 decibel.
(3). Air Exhaust Cabinet used for pumping air out of drum from the main machine, making the working area under the negative pressure and equipped with filtrating equipment, dust removal system and dust collecting system. The operating noise of the whole cabinet is less than 90 decibel.
(4).Air spray system the system is made up with peristaltic pump, air spray gun and material connecting line, used for atomizing coating mediums, when coating sugar film, it should be equipped with the dropper.
(5).Thermostatic stirrer
It is used for preparing the film coating mediums composed by liquid touchable plate, electrical heating system, pneumatically motorized stirring system and so on.
4. Performance and Characteristics
All operations can be finished through pushing the touch key on the computer controlled panel, with reliable and stable in performance. The streamline guiding-type mixer drives tablets to make easy and smooth rotation without fragment and chipped edge, which improves the yields. The guiding sheet has a narrow surface, to which no dressing can be stuck, economizing on dressing and improving the quality of finished products select the imported spray gun. It's convenient to operate and easy to master and flexible controlled technological requirement. The spray gun head requirement must keep in the range of 0.29 Mpa to 0.39 Mpa, with adjustable angle and sector, and with such features just as uniform particle, uniform atomization, large spray area, no dropping leakage, no blockage, uniform atomization and large spray area, practical to adjust flow, free leakage and blockage, dressing economized etc, which is well reputed by the user.
5. Technical Parameter
Max load: 350kgs
Mainframe Power: 3kw
Roller Rotate Speed: 2-12rpm
Mainframe Weight: 1200kgs
Mainframe form size (L*W*H): 2800*2000*2200
Hot air machine power: 1.5kw
Hot air machine form size: 1200*1200*2200mm³
Hot air machine weight: 800kgs
Clean dust air outlet machine power: 5.5kw
Clean dust air outlet form size: 890*1000*2200mm³
Clean dust air outlet machine weight: 800kgs
Heat preservation beater: 3kw
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
