Water Bottling Machine
Introduction:
This machine is for pure water,mineral water filling and packing.bottle size from 3 liter to 10 liter or more.
Water Bottling Machine Technology data:
1.Model: CGF8-8-3
2.Capacity:800-1000B/H
3.Material: The material which contact directly with the liquid is the SUS304 (Food grade), made in china. The transmission mechanism and the gear are equipped with firing A4 carbon steel.
4.The 3-in-1 is mainly used to fill pure water, Mineral water, wine.
5. Water Bottling Machine Characteristic:
5.1.The all machine applies bottle handling technical and the filling valves go up-down when filling, which make sure the bottle filling goes stable, reliable during high speed. The bottle handling technical also make the different bottle changing easily without changing too many accessories.
5.2.This machine uses new generation stainless steel spring washing clips and the clips do not contact the upside of bottle screw avoiding the second pollution. It can both clear the inside and the outside of the bottle.
5.3.The advanced normal pressure filling principle was applied. Filling is quick, and stable. Not contacting with the liquid avoids second pollution and oxidation.
5.4.This machine applies magnetic force screw type sealing, realizing auto grasping cap, sealing. The sealing cap force can be adjusted.
5.5.Independent electricity box makes sure every electrical appliance works normally.
6. Water Bottling Machine Disposition :
6.1Motor: SIEMENS
6.2Speed reducer: Hangzhou JIE brand
6.3Invert speed control: Japanese Mitsubishi
6.4PLC: Japanese Mitsubishi
6.5Touch screen: Taiwan WEINVIEW
6.6Electricity appliance: DELIXI
7.Volume of PET bottle : 3L-10L
8.Cap diameter: plastic screw type
9.Filling temperature: Normal temperature
10.Filling pressure: Normal
11.Filling precision: ±2-3%
12.Pressure of washing: 0.2Mpa
13.Washing consuming clear water: 300kg/h
14.Gas consumption: 0.4m³ /min
15.Power of main motor:4.4KW
16.Dimension: 2230×1630×2250mm
17.Weight: 2200KG
