Bundle wrapping machine
.
Automatic Shrink Wrapper Shrink Bundle Machine
Technical data
1) Sealing type: sleeve sealing
2) Power supply: 380V/ 50-60Hz/ 3phase
3) Max product size: 420(W) x 300(H) mm
4) Film: one roll of printed polyethylene (PE) film
5) Infeed conveyor: 2300mm (standard machine)
6) Packing capacity: 10-20packs/min
7) Max film size: 630 (width) x 280mm(outer diameter)
8) Rated power consumption: 20.5 kW (max.)
9) Tunnel oven size: 1800mm(L), entrance 600(W) x 400(H) mm
10) Tunnel conveyor speed: controlled by frequency converter, 15 m/min
11) Tunnel conveyor: chains with rotating silicon coated rods
12) Working height: 780-850 mm
13) Air pressure: <= 0.5MPa (5 bar)
14) PLC: SIEMENS S7
15) Sealing system: permanently heated seal bar coated Teflon with easy-exchangeable sealing blade
16) Operating interface: Eview displayer
17) Machine material: carbon steel
18) Machine dimensions: 3500 x 1100 x 1650 mm
Product show
