Jam Cup Packing Machine
Main Fittings
1.Electric Fittings: Yatai PID Self-adjusting Automatic Temperature Control Meter, Schneider
Pushbutton, Selector Switches, Pilot Lights, Contactor and Thermal Overload Relay, Korea LG Circuit-breaker;
2.Lubricating System: Taiwan Famous Automatic Oiling System;
3.Pneumatic System: Japan SMC;
4.Hydraulic System:Guangye hydraulic the pump and Taiwan Lianton hydraulic the electromagnetism valve.
Main Parameters for Jam Cup Packing Machine
Model |
BF-H4 |
BF-H6 |
BF-H8 |
BF-H10 |
Production capacity |
3000-4000Cups/H |
5000-6000Cups/H |
7000-8000Cups/H |
9000-10000Cups/H |
Filling range |
50-450ml |
|||
Air consumption |
0.8m3/Min |
1m3/Min |
1.2m3/Min |
1.6m3/Min |
Voltage |
220V,50HZ |
|||
Power |
3.5Kw |
5Kw |
6Kw |
7.5Kw |
Weight |
700Kg |
800Kg |
1000Kg |
1200Kg |
Overall dimension |
3300x710x1700mm |
3800x630 x1700mm |
3800x710x1700mm |
4000x800x1700mm |
Function for Jam Cup Packing Machine
1.The shape of machine is beautiful, clean and bright.
2.The place which contact with raw material is made of stainless steel and meet food sanitation standard.
3.Adopt pneumatic transmission, the whole process is completely automatic from container supplying, filling, sealing, cutting, end product push to scrap rewind.
4.The machine can fill, seal and cut several containers at the same time, improve the production efficiency.
5.The machine has photoelectric eyes, it can automatically correct the film sealing position and ensure the sealing position is right.
6.The machine is fit for filling and sealing all kinds of liquid and cream products, such as jelly, milk, ice cream, mineral water, juice, jam, etc.
