3 Colours Jelly Filling Sealing Machine

3 Colours Jelly Filling Sealing Machine photo-1
US$ 58,000 - 60,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Cans, Capsule
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Cans, Capsule
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220v
Power 1.5Kw
Brand Name Mars
Model Number MA-GDP-1
Dimension(L*W*H) L15xW0.9xH1.7m
Weight 4000Kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

3 Colours Jelly Filling Sealing Machine



Features:
1. Pneumaticl cup falling.
2. Two-step piston filling device permits adjustment of filling quantity.
3. Two-step sealing make sure the film firm, and have a high percent of finished product.
4. Feeding materials from charging bucket automatically.
5. The photoelectric tracing device can be assure of the seal design correct.
6. Stainless steel sealing knife for rust-free performance.



3 Colours Jelly Filling Sealing Machine



Technique parameter for 3 Colours Jelly Filling Sealing Machine :

Model GDP-3  GDP-4 GDP-10 GDP-12
Packing Speed 2800-3600Pcs/H 4800-5800Pcs/H 10000-12000Pcs/H 12000-14000Pcs/H
Width of Filim Sealing 340mm 340mm 340mm 340mm
Capacity of Filling 100ml 80ml 25ml 15ml
Power Supply Thri-phase,4-wires
Motor 1.5Kw
Heating Power 4Kw 4Kw 6Kw 10Kw
Air Pressure 0.5 Mpa-0.7 Mpa 0.5 Mpa-0.7 Mpa 0.5 Mpa-0.7 Mpa 0.5 Mpa-0.7 Mpa
Air Wastage 0.6-1 m3 /Min
Overall Size L15×W0.9×H1.7m L15×W0.9×H1.7m L13×W0.9×H1.7m L13×W0.9×H1.7m
Speed Regulating Method Frequency-inverted regulating
Weight 4000Kg

3 Colours Jelly Filling Sealing Machine
                                  3 Colours Jelly Filling Sealing Machine

                               3 Colours Jelly Filling Sealing Machine

3 Colours Jelly Filling Sealing Machine
3 Colours Jelly Filling Sealing Machine3 Colours Jelly Filling Sealing Machine3 Colours Jelly Filling Sealing Machine3 Colours Jelly Filling Sealing Machine3 Colours Jelly Filling Sealing Machine3 Colours Jelly Filling Sealing Machine
