Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Hdpe Injection Molding Machine
Hdpe Injection Molding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Injection Blow Molding, Hdpe Injection Molding Machine
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Huangyan 4 Cavity PET Blowing MachineUS$ 45,000 - 50,000MOQ: 1 Piece -
20 Liter Bottle Blowing MachineUS$ 14,000 - 15,000MOQ: 1 Set
-
3 Cavities Full-automatic PET Blowing MachineUS$ 10,000 - 13,000MOQ: 1 Set
-
Full Auto Blow Moulding MachineUS$ 45,000 - 50,000MOQ: 1 Set
-
Full Automatic Plastic Injection MachineUS$ 25,000 - 30,000MOQ: 1 Set
Condition
New
Type
Other, Injection Blow Molding, Hdpe Injection Molding Machine
Style
Horizontal
Brand Name
Mars
Model Number
HIM-228
Place of Origin
Jiangsu, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
212 Mpa
Injection Rate
187 g/s
Clamping Force
212 Mpa
Opening Stroke
490 mm
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Hdpe Injection Molding Machine
Name of item |
UNIT |
A |
B |
|
Screw Diameter |
MM |
50 |
55 |
|
Screw L/D Ratio |
L/D |
22 |
20 |
|
Shot Volume |
Cm3 |
461 |
558 |
|
Shot weight (ps) |
G |
420 |
508 |
|
|
Oz |
15 |
18 |
|
Rate of injection (ps) |
g/s |
154 |
187 |
|
Plasticizing Capacity (ps) |
g/s |
32.5 |
39.2 |
|
Injection pressure |
Mpa |
212 |
175 |
|
Screw Speed Range |
Rpm |
3-200 |
||
Mould Clamping Force |
KN |
2280 |
||
Opening Stroke |
MM |
490 |
||
Space Between tie and Bars |
MM |
520*500 |
||
Max. Mould Thickness |
MM |
540 |
||
Min. Mould Thickness |
MM |
200 |
||
Ejector Stroke |
MM |
160 |
||
Ejector Force |
KN |
61 |
||
Ejector point |
PC |
5 |
||
Max. pump pressure |
Mpa |
16 |
||
Motor Power |
KW |
18.5(22) |
||
Heating Power |
KW |
12.5 |
||
Oil Tank Capacity |
L |
310 |
||
Machine Size (L*W*H) |
M |
5.1*1.5*1.95 |
||
Machine Weight |
T |
7.2 |
||
Product show
