Help CenterSS304 Mixing Tank (steam Heating and Water Cooling)
Related Products
-
CO2 Carbonated Soft Drinks Blending/ Mixing MachineUS$ 5,000 - 15,000MOQ: 1 Set -
High Content CO2 And Water Mixing MachineUS$ 4,000 - 6,000MOQ: 1 Piece
-
Beverage Mixing TankUS$ 1,800 - 2,600MOQ: 1 Piece
-
Soft Drink Mixing MachineUS$ 10,000 - 13,000MOQ: 1 Piece
-
Stainless Steel Mixing TankUS$ 1,500 - 2,000MOQ: 1 Piece
Mixing Tank
Classification
1. According to Structure: opening on the head & conical sealed head on the bottom, up & down elliptical sealed head
2. According to Heating Type: there are Steam Heating and Electric Heating
3. According to Volume: there are 100L-10000L, also can design and facture in accordance with customers’ requirements.
Structure
Tank body is mainly used to develop and ferment all kinds of bacterial, so the seal is good ( to prevent bacterial contamination).
The inner pot has an agitator to a stirring effect.
Body Material:
a). Stainless steel inner pot(SUS304/SUS316L), carbon steel outer pot (Q235-B) treated with anti-rust paint
b). the whole machine is made of stainless steel (SUS304/SUS316L)
Characteristics
1. This machine can be CIP cleaned online, SIP sterilization (121°C/0.1MPa).
2. Designed in accordance with sanitary requirement, so the structural design is very user-friendly and easy to operate. While, smooth transmission, low noise.
3. There is appropriate diameter; the stirring device is made on demand, energy-saving, stirring, good fermentation effect.
4. The inner surface is mirror-polished (roughness Ra≤0.4µm); the weld of the inner pot with inlet, outlet, sight mirror and manhole use stretch flanging arc transition. No dead corners ensure the reliability and stability in the producing process.
Technical Parameters
Volume |
300L |
400L |
500L |
600L |
800L |
1000L |
1500L |
2000L |
3000L |
Body diameter(mm) |
Φ800 |
Φ800 |
Φ900 |
Φ1000 |
Φ1000 |
Φ1000 |
Φ1200 |
Φ1300 |
Φ1600 |
Body height(mm) |
600 |
800 |
800 |
800 |
1000 |
1220 |
1220 |
1500 |
1500 |
Motor power(kw) |
0.55 |
0.55 |
0.75 |
0.75 |
0.75 |
0.75 |
1.5 |
2.2 |
3 |
Stirring speed(rpm) |
36r/min |
||||||||
Working pressure |
≤0.09Mpa |
||||||||
Working temperature |
<100°C |
||||||||
Accessories |
Sanitary manhole, cleaning ball,safety valve,pressure gauge |
||||||||
Notes:
1. The nominal capacity and size in the chart is standard configuration. Any specific requirements, please point out.
2. The jacket working pressure≤ 0.09Mpa also can be made according to customers’ requirements.
3. The process parameters that need provided when choosing the fermentation tank: the nature of material, working pressure, temperature, specific requirements, etc.
Product show
