Place of Origin Zhejiang, China
Brand Name HH
Model Number Customized
Type Other, food machine
After-sales Service Provided Engineers available to service machinery overseas



ELECTRICAL TANK is mainly used in the heating, heat preservation, sterilization, cooling,aging and storage of liquid material.



ELECTRICAL TANK is mainly used in the heating, heat preservation, sterilization, cooling,
aging and storage of liquid material, during the industries of dairy products,
ice cream, pharmacy, chemical industry, cosmetic, and so on.
It's of many advantages of energy conservation, noise elimination, acid-proof, strong
productivity, and easily washable and so on.



1,Usage



   Aging tank(have another name called hot and cold tank), have advantages such as energy-conservation , eliminate noise , able to bear rotten, production capacity strong, wash conveniently, extensive in industrial departments , such as dairy products trade , food, medicine, chemical industry , beverage ,etc., heat , cool , keep warm , the bar especially suitable for the milk is disinfected and kept warm, it is the essential equipment in the production line of ice cream.







2,Structure



This equipment is made up by interior gallbladder , inserting set , heat preservation , other foreskin , decelerator , paddle , thermometer ,etc..



1), Interior gallbladder:  Adopt 304 materials of stainless steel board, surface polishing.



2), The middle level is inserted set:  Adopt carbon steel plate or 1Cr18Ni9Ti stencil plate , enclose spiral device to strengthen, from top to bottom cooled water (have no pressure), achieve the best purpose to rise and lowering the temperature.



3), Group of warm keeping: polishing fish scale pattern and succeed by board by stainless steel, with gather heat preservation ammonia fat or glass wool keep with external temperature, get the result of keeping warm.



4), Decelerator : Wave line needle wheel planetary decelerator, fix on bracket of crossbeam, decelerator wheel produce axle and paddle link, adopt kink hookup , convenient disassemble and washing.



5), Thermometer: Specification 00C~1000C, install it on the crossbeam , stretches the minimum medium position directly , make liquid material use minimum position can is it produce temperature to instruct too , achieve the goal of disinfect and aging.



 Technical parameter



Volume

300L

400L

500L

600L

800L

1000L

1500L

2000L

3000L

Body diameter(mm)

Φ800

Φ800

Φ900

Φ1000

Φ1000

Φ1000

Φ1200

Φ1300

Φ1600

Body height(mm)

600

800

800

800

1000

1220

1220

1500

1500

Motor power(kw)

0.55

0.55

0.55

0.55

0.55

0.75

1.5

2.2

3

Mixing speed(rpm)

36r/min

Working pressure

≤0.09Mpa

Working temperature

<100°C

Basic valve

Temperature meter,safety valve,pressure meter







Note:



1,The parameters above are standard ,any special requirement, please put forward.



2,Interlayer’s working pressure ≤0.09Mpa,can be made according to special require.



3,Parameters like material, working pressure, working temperature and any special request should be noted.
